Filter
| Code | USA Ref | 3D Drawings | Tube | A | B | L1 | L2 | CH | D1 | D | Bag | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50550 00 N01 | 50550-4-M5 | Request access | 4 (5/32) | M5 | .142 (3.6) | .748 (19) | .965 (24.5) | - | CH8 | .394 (10) | 10 | |
| 50550 00 N02 | 50550-4-1/8 | Request access | 4 (5/32) | 1/8 | .213 (5.4) | .827 (21) | 1.102 (28) | .197 (5) | .551 (14) | .394 (10) | 10 | |
| 50550 00 N12 | 50550-5-M5 | Request access | 5 | M5 | .142 (3.6) | .787 (20) | .965 (24.5) | - | CH8 | .492 (12.5) | 10 | |
| 50550 00 N13 | 50550-5-1/8 | Request access | 5 | 1/8 | .213 (5.4) | .846 (21.5) | 1.102 (28) | .197 (5) | .551 (14) | .492 (12.5) | 10 | |
| 50550 00 N14 | 50550-5-1/4 | Request access | 5 | 1/4 | .280 (7.1) | .965 (24.5) | 1.220 (31) | .236 (6) | .669 (17) | .492 (12.5) | 10 | |
| 50550 00 N15 | 50550-6-M5 | Request access | 6 | M5 | .142 (3.6) | .807 (20.5) | .965 (24.5) | - | CH8 | .492 (12.5) | 10 | |
| 50550 00 N03 | 50550-6-1/8 | Request access | 6 | 1/8 | .213 (5.4) | .886 (22.5) | 1.102 (28) | .197 (5) | .551 (14) | .492 (12.5) | 10 | |
| 50550 00 N04 | 50550-6-1/4 | Request access | 6 | 1/4 | .280 (7.1) | .984 (25) | 1.220 (31) | .236 (6) | .669 (17) | .492 (12.5) | 10 | |
| 50550 00 N05 | 50550-8-1/8 | Request access | 8 (5/16) | 1/8 | .213 (5.4) | .945 (24) | 1.102 (28) | .197 (5) | .551 (14) | .551 (14) | 10 | |
| 50550 00 N06 | 50550-8-1/4 | Request access | 8 (5/16) | 1/4 | .280 (7.1) | 1.024 (26) | 1.220 (31) | .236 (6) | .669 (17) | .551 (14) | 10 | |
| 50550 00 N07 | 50550-8-3/8 | Request access | 8 (5/16) | 3/8 | .319 (8.1) | 1.102 (28) | 1.398 (35.5) | .276 (7) | .787 (20) | .551 (14) | 10 | |
| 50550 00 N08 | 50550-10-1/4 | Request access | 10 | 1/4 | .280 (7.1) | 1.142 (29) | 1.220 (31) | .236 (6) | .669 (17) | .669 (17) | 10 | |
| 50550 00 N09 | 50550-10-3/8 | Request access | 10 | 3/8 | .319 (8.1) | 1.201 (30.5) | 1.398 (35.5) | .276 (7) | .787 (20) | .669 (17) | 10 | |
| 50550 00 N11 | 50550-12-3/8 | Request access | 12 | 3/8 | .319 (8.1) | 1.280 (32.5) | 1.398 (35.5) | .276 (7) | .787 (20) | .846 (21.5) | 10 |
