01VT
BUTTON OPERATED VALVES - METRIC
| Code | USA Ref | 3D Drawings | Ways | Reactuation | Function | Size | Bag | |
|---|---|---|---|---|---|---|---|---|
| 01V T0 3 NC 02 | 01VT03NC02 | Request access | 3/2 | BUTTON OPERATED - SPRING RETURN | NC | G 1/8 | 1 | |
| 01V T0 3 NC 03 | 01VT03NC03 | Request access | 3/2 | BUTTON OPERATED - SPRING RETURN | NC | G 1/4 | 1 | |
| 01V T1 3 00 02 | 01VT130002 | Request access | 3/2 | BUTTON OPERATED - PUSH/PULL | G 1/8 | 1 | ||
| 01V T1 3 00 03 | 01VT130003 | Request access | 3/2 | BUTTON OPERATED - PUSH/PULL | G 1/4 | 1 | ||
| 01V T0 5 00 02 | 01VT050002 | Request access | 5/2 | BUTTON OPERATED - SPRING RETURN | G 1/8 | 1 | ||
| 01V T0 5 00 03 | 01VT050003 | Request access | 5/2 | BUTTON OPERATED - SPRING RETURN | G 1/4 | 1 | ||
| 01V T1 5 00 02 | 01VT150002 | Request access | 5/2 | BUTTON OPERATED - PUSH/PULL | G 1/8 | 1 | ||
| 01V T1 5 00 03 | 01VT150003 | Request access | 5/2 | BUTTON OPERATED - PUSH/PULL | G 1/4 | 1 |
