Filter
| Code | USA Ref | 3D Drawings | Drawing | Way | Function | Size | Control 12 | Return 10 | Flow rate Nl/min. | Ø inch (mm) | Response Time (ms) En. | Response Time (ms) De-en. | Pressure psi (bar) min. | Pressure psi (bar) max. | Pressure psi (bar) supply | Pressure psi (bar) control | Weight lb (Kg) | Coil | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UAF 25 50 N | UAF2550N | Request access | 2/2 | NC | 1 NPT | electric amplified | pneumatic + spring | 1600 | .984 (25) | 23 | 55 | 29 (2) | 145 (10) | - | - | 2.34 (1.06) | U2 | ||
| UAF 25 51 N | UAF2551N | Request access | 2/2 | NC | 1 NPT | electric amplified | pneumatic + spring | 1600 | .984 (25) | 23 | 55 | 29 (2) | 145 (10) | - | - | 2.34 (1.06) | U2 | ||
| UAF 25 52 N | UAF2552N | Request access | 2/2 | NC | 1 NPT | electric amplified | pneumatic + spring | 1600 | .984 (25) | 23 | 35 | - | - | 87 (6) | 58 (4) | 2.34 (1.06) | U2 |
