| Code | USA Ref | 3D Drawings | Duty cycle ED (a) % | Power consumption W Hold | Power consumption W Inrush | Tolerance tension % | Rated voltage | Weight lb (Kg) | |
|---|---|---|---|---|---|---|---|---|---|
| UDB 0501 | UDB0501 | Request access | 100 | 11 | 11 | ±10 | 12 V DC | 0.13 (0.06) | |
| UDB 0502 | UDB0502 | Request access | 100 | 11 | 11 | ±10 | 24 V DC | 0.13 (0.06) | |
| UDB 0507 | UDB0507 | Request access | 100 | 10 VA (Max) | 16 VA (Max) | ±10 | 24 V AC/50-60 HZ | 0.13 (0.06) | |
| UDB 0509 | UDB0509 | Request access | 100 | 10 VA (Max) | 16 VA (Max) | ±10 | 110 V AC/50-60 HZ | 0.13 (0.06) | |
| UDB 0510 | UDB0510 | Request access | 100 | 10 VA (Max) | 16 VA (Max) | ±10 | 230 V AC/50-60 HZ | 0.13 (0.06) |
