| Code | USA Ref | 3D Drawings | Way | Size | Control 14 | Return 12 | Response Time (ms) En. | Response Time (ms) De-en. | Pressure psi (bar) | Weight lb (Kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| UAC 7500 | UAC7500 | Request access | 5/2 | G 1/8 | electric amplified | pneumatic + spring | 18 | 20 | 26 ÷ 145 (1.8 ÷ 10) | 0.60 (0.27) | |
| UAC 8500 | UAC8500 | Request access | 5/2 | G 1/4 | electric amplified | pneumatic + spring | 22 | 22 | 33 ÷ 145 (2.3 ÷ 10) | 0.62 (0.28) | |
| UAC 9500 | UAC9500 | Request access | 5/2 | G 1/2 | electric amplified | pneumatic + spring | 23 | 30 | 29 ÷ 145 (2 ÷ 10) | 2.43 (1.1) |
