| Code | USA Ref | 3D Drawings | Drawing | Duty cycle ED (a) % | Power consumption W Hold | Power consumption W Inrush | Tolerance tension % | Rated voltage | Weight lb (Kg) | |
|---|---|---|---|---|---|---|---|---|---|---|
| UDC 0301 | UDC0301 | Request access | 100 | 2.5 | 2.5 | ±10 | 12 V DC | 0.18 (0.08) | ||
| UDC 0302 | UDC0302 | Request access | 100 | 2.5 | 2.5 | ±10 | 24 V DC | 0.18 (0.08) | ||
| UDC 0307 | UDC0307 | Request access | 100 | 3,3 VA (Max) | 5 VA (Max) | ±10 | 24 V AC/50-60 HZ | 0.18 (0.08) | ||
| UDC 0309 | UDC0309 | Request access | 100 | 3,3 VA (Max) | 5 VA (Max) | ±10 | 110 V AC/50-60 HZ | 0.18 (0.08) | ||
| UDC 0310 | UDC0310 | Request access | 100 | 3,3 VA (Max) | 5 VA (Max) | ±10 | 230 V AC/50-60 HZ | 0.18 (0.08) |
