Filter
N100
FR + L - NPTF
*Automatic with float (max 8 bar)
| Code | USA Ref | 3D Drawings | Size | Thread (NPTF) | Filtration | Regulation | Flow Rate | Exhaust | A | B | C | D | E | F | H | I | J | K1 | K2 | L | P | Q | R | W | Y | Z | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| N100 204 121 200 | N100204121200 | Request access | FR+L2 | 3/8 | 5 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 222 200 | N100204222200 | Request access | FR+L2 | 3/8 | 20 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 131 200 | N100205131200 | Request access | FR+L2 | 1/2 | 5 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 232 200 | N100205232200 | Request access | FR+L2 | 1/2 | 20 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 309 131 200 | N100309131200 | Request access | FR+L3 | 1 | 5 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 122 100 | N100204122100 | Request access | FR+L2 | 3/8 | 5 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 132 100 | N100205132100 | Request access | FR+L2 | 1/2 | 5 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 241 100 | N100205241100 | Request access | FR+L2 | 1/2 | 20 µm | 0÷12 Bar (174 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 309 132 100 | N100309132100 | Request access | FR+L3 | 1 | 5 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 122 200 | N100204122200 | Request access | FR+L2 | 3/8 | 5 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 231 200 | N100204231200 | Request access | FR+L2 | 3/8 | 20 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 132 200 | N100205132200 | Request access | FR+L2 | 1/2 | 5 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 241 200 | N100205241200 | Request access | FR+L2 | 1/2 | 20 µm | 0÷12 Bar (174 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 309 132 200 | N100309132200 | Request access | FR+L3 | 1 | 5 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 131 100 | N100204131100 | Request access | FR+L2 | 3/8 | 5 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 232 100 | N100204232100 | Request access | FR+L2 | 3/8 | 20 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 141 100 | N100205141100 | Request access | FR+L2 | 1/2 | 5 µm | 0÷12 Bar (174 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 131 100 | N100307131100 | Request access | FR+L3 | 3/4 | 5 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 309 141 100 | N100309141100 | Request access | FR+L3 | 1 | 5 µm | 0÷12 Bar (174 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 131 200 | N100204131200 | Request access | FR+L2 | 3/8 | 5 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 232 200 | N100204232200 | Request access | FR+L2 | 3/8 | 20 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 141 200 | N100205141200 | Request access | FR+L2 | 1/2 | 5 µm | 0÷12 Bar (174 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 131 200 | N100307131200 | Request access | FR+L3 | 3/4 | 5 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 309 141 200 | N100309141200 | Request access | FR+L3 | 1 | 5 µm | 0÷12 Bar (174 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 132 100 | N100204132100 | Request access | FR+L2 | 3/8 | 5 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 241 100 | N100204241100 | Request access | FR+L2 | 3/8 | 20 µm | 0÷12 Bar (174 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 211 100 | N100205211100 | Request access | FR+L2 | 1/2 | 20 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 132 100 | N100307132100 | Request access | FR+L3 | 3/4 | 5 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 309 231 100 | N100309231100 | Request access | FR+L3 | 1 | 20 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 132 200 | N100204132200 | Request access | FR+L2 | 3/8 | 5 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 241 200 | N100204241200 | Request access | FR+L2 | 3/8 | 20 µm | 0÷12 Bar (174 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 211 200 | N100205211200 | Request access | FR+L2 | 1/2 | 20 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 132 200 | N100307132200 | Request access | FR+L3 | 3/4 | 5 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 309 231 200 | N100309231200 | Request access | FR+L3 | 1 | 20 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 141 100 | N100204141100 | Request access | FR+L2 | 3/8 | 5 µm | 0÷12 Bar (174 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 111 100 | N100205111100 | Request access | FR+L2 | 1/2 | 5 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 212 100 | N100205212100 | Request access | FR+L2 | 1/2 | 20 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 141 100 | N100307141100 | Request access | FR+L3 | 3/4 | 5 µm | 0÷12 Bar (174 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 309 232 100 | N100309232100 | Request access | FR+L3 | 1 | 20 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 141 200 | N100204141200 | Request access | FR+L2 | 3/8 | 5 µm | 0÷12 Bar (174 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 111 200 | N100205111200 | Request access | FR+L2 | 1/2 | 5 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 212 200 | N100205212200 | Request access | FR+L2 | 1/2 | 20 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 141 200 | N100307141200 | Request access | FR+L3 | 3/4 | 5 µm | 0÷12 Bar (174 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 309 232 200 | N100309232200 | Request access | FR+L3 | 1 | 20 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 211 100 | N100204211100 | Request access | FR+L2 | 3/8 | 20 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 112 100 | N100205112100 | Request access | FR+L2 | 1/2 | 5 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 221 100 | N100205221100 | Request access | FR+L2 | 1/2 | 20 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 231 100 | N100307231100 | Request access | FR+L3 | 3/4 | 20 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 309 241 100 | N100309241100 | Request access | FR+L3 | 1 | 20 µm | 0÷12 Bar (174 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 211 200 | N100204211200 | Request access | FR+L2 | 3/8 | 20 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 112 200 | N100205112200 | Request access | FR+L2 | 1/2 | 5 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 221 200 | N100205221200 | Request access | FR+L2 | 1/2 | 20 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 231 200 | N100307231200 | Request access | FR+L3 | 3/4 | 20 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 309 241 200 | N100309241200 | Request access | FR+L3 | 1 | 20 µm | 0÷12 Bar (174 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 212 100 | N100204212100 | Request access | FR+L2 | 3/8 | 20 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 121 100 | N100205121100 | Request access | FR+L2 | 1/2 | 5 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 222 100 | N100205222100 | Request access | FR+L2 | 1/2 | 20 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 232 100 | N100307232100 | Request access | FR+L3 | 3/4 | 20 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 212 200 | N100204212200 | Request access | FR+L2 | 3/8 | 20 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 121 200 | N100205121200 | Request access | FR+L2 | 1/2 | 5 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 222 200 | N100205222200 | Request access | FR+L2 | 1/2 | 20 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 232 200 | N100307232200 | Request access | FR+L3 | 3/4 | 20 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 221 100 | N100204221100 | Request access | FR+L2 | 3/8 | 20 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 122 100 | N100205122100 | Request access | FR+L2 | 1/2 | 5 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 241 100 | N100307241100 | Request access | FR+L3 | 3/4 | 20 µm | 0÷12 Bar (174 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 112 200 | N100204112200 | Request access | FR+L2 | 3/8 | 5 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 221 200 | N100204221200 | Request access | FR+L2 | 3/8 | 20 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 122 200 | N100205122200 | Request access | FR+L2 | 1/2 | 5 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 231 200 | N100205231200 | Request access | FR+L2 | 1/2 | 20 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 241 200 | N100307241200 | Request access | FR+L3 | 3/4 | 20 µm | 0÷12 Bar (174 psi) | 183,6 cmf (5200 NI/min) | Depressure drain | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 204 121 100 | N100204121100 | Request access | FR+L2 | 3/8 | 5 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 222 100 | N100204222100 | Request access | FR+L2 | 3/8 | 20 µm | 0÷4 Bar (58 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 205 131 100 | N100205131100 | Request access | FR+L2 | 1/2 | 5 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 307 131 100 | N100309131100 | Request access | FR+L3 | 1 | 5 µm | 0÷8 Bar (116 psi) | 183,6 cmf (5200 NI/min) | Automatic with float | 7.086 (180) | 12.952 (329) | 3.779 (96) | 3.503 (89) | 1.850 (47) | 1.811 (46) | 6.338 (161) | 3.051 (77,5) | 6.594 (167,5) | 2.598 (66) | 2.165 (55) | 0.255 (6,5) | 2.283 (58) | Tube 8-6 | 7.992 (203) | 3/4 - 1 | 2.755 (70) | 3.110 (79) | |
| N100 103 111 100 | N100103111100 | Request access | FR+L1 | 1/4 | 5 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 111 200 | N100103111200 | Request access | FR+L1 | 1/4 | 5 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 112 100 | N100103112100 | Request access | FR+L1 | 1/4 | 5 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 204 231 100 | N100204231100 | Request access | FR+L2 | 3/8 | 20 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 103 112 200 | N100103112200 | Request access | FR+L1 | 1/4 | 5 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 121 100 | N100103121100 | Request access | FR+L1 | 1/4 | 5 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 205 231 100 | N100205231100 | Request access | FR+L2 | 1/2 | 20 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 103 121 200 | N100103121200 | Request access | FR+L1 | 1/4 | 5 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 205 232 100 | N100205232100 | Request access | FR+L2 | 1/2 | 20 µm | 0÷8 Bar (116 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 103 122 100 | N100103122100 | Request access | FR+L1 | 1/4 | 5 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 122 200 | N100103122200 | Request access | FR+L1 | 1/4 | 5 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 131 100 | N100103131100 | Request access | FR+L1 | 1/4 | 5 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 131 200 | N100103131200 | Request access | FR+L1 | 1/4 | 5 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 132 100 | N100103132100 | Request access | FR+L1 | 1/4 | 5 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 132 200 | N100103132200 | Request access | FR+L1 | 1/4 | 5 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 141 100 | N100103141100 | Request access | FR+L1 | 1/4 | 5 µm | 0÷12 Bar (174 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 141 200 | N100103141200 | Request access | FR+L1 | 1/4 | 5 µm | 0÷12 Bar (174 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 211 100 | N100103211100 | Request access | FR+L1 | 1/4 | 20 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 211 200 | N100103211200 | Request access | FR+L1 | 1/4 | 20 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 212 100 | N100103212100 | Request access | FR+L1 | 1/4 | 20 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 212 200 | N100103212200 | Request access | FR+L1 | 1/4 | 20 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 221 100 | N100103221100 | Request access | FR+L1 | 1/4 | 20 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 221 200 | N100103221200 | Request access | FR+L1 | 1/4 | 20 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 222 100 | N100103222100 | Request access | FR+L1 | 1/4 | 20 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 222 200 | N100103222200 | Request access | FR+L1 | 1/4 | 20 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 231 100 | N100103231100 | Request access | FR+L1 | 1/4 | 20 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 231 200 | N100103231200 | Request access | FR+L1 | 1/4 | 20 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 232 100 | N100103232100 | Request access | FR+L1 | 1/4 | 20 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 232 200 | N100103232200 | Request access | FR+L1 | 1/4 | 20 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 241 100 | N100103241100 | Request access | FR+L1 | 1/4 | 20 µm | 0÷12 Bar (174 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 103 241 200 | N100103241200 | Request access | FR+L1 | 1/4 | 20 µm | 0÷12 Bar (174 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 111 100 | N100104111100 | Request access | FR+L1 | 3/8 | 5 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 111 200 | N100104111200 | Request access | FR+L1 | 3/8 | 5 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 112 100 | N100104112100 | Request access | FR+L1 | 3/8 | 5 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 112 200 | N100104112200 | Request access | FR+L1 | 3/8 | 5 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 121 100 | N100104121100 | Request access | FR+L1 | 3/8 | 5 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 121 200 | N100104121200 | Request access | FR+L1 | 3/8 | 5 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 122 100 | N100104122100 | Request access | FR+L1 | 3/8 | 5 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 122 200 | N100104122200 | Request access | FR+L1 | 3/8 | 5 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 131 100 | N100104131100 | Request access | FR+L1 | 3/8 | 5 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 131 200 | N100104131200 | Request access | FR+L1 | 3/8 | 5 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 132 100 | N100104132100 | Request access | FR+L1 | 3/8 | 5 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 132 200 | N100104132200 | Request access | FR+L1 | 3/8 | 5 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 141 100 | N100104141100 | Request access | FR+L1 | 3/8 | 5 µm | 0÷12 Bar (174 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 141 200 | N100104141200 | Request access | FR+L1 | 3/8 | 5 µm | 0÷12 Bar (174 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 211 100 | N100104211100 | Request access | FR+L1 | 3/8 | 20 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 211 200 | N100104211200 | Request access | FR+L1 | 3/8 | 20 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 212 100 | N100104212100 | Request access | FR+L1 | 3/8 | 20 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 212 200 | N100104212200 | Request access | FR+L1 | 3/8 | 20 µm | 0÷2 Bar (29 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 221 100 | N100104221100 | Request access | FR+L1 | 3/8 | 20 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 221 200 | N100104221200 | Request access | FR+L1 | 3/8 | 20 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 222 100 | N100104222100 | Request access | FR+L1 | 3/8 | 20 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 222 200 | N100104222200 | Request access | FR+L1 | 3/8 | 20 µm | 0÷4 Bar (58 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 231 100 | N100104231100 | Request access | FR+L1 | 3/8 | 20 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 231 200 | N100104231200 | Request access | FR+L1 | 3/8 | 20 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 232 100 | N100104232100 | Request access | FR+L1 | 3/8 | 20 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 232 200 | N100104232200 | Request access | FR+L1 | 3/8 | 20 µm | 0÷8 Bar (116 psi) | 53 cmf (1500 Nl/Min) | Automatic with float | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 241 100 | N100104241100 | Request access | FR+L1 | 3/8 | 20 µm | 0÷12 Bar (174 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 104 241 200 | N100104241200 | Request access | FR+L1 | 3/8 | 20 µm | 0÷12 Bar (174 psi) | 53 cmf (1500 Nl/Min) | Depressure drain | 4.016 (102) | 9.173 (233) | 2.244 (57) | 2.244 (57) | 1.280 (32.5) | 1.004 (25.5) | 4.685 (119) | 1.870 (47.5) | 3.878 (98.5) | 1.772 (45) | 1.398 (35.5) | 0.217 (5.5) | 1.358 (34.5) | E.D. 256 (6,5) | 5.669 (144) | 1/4 - 3/8 | 0.276 (7) | 2.244 (57) | |
| N100 204 111 100 | N100204111100 | Request access | FR+L2 | 3/8 | 5 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 111 200 | N100204111200 | Request access | FR+L2 | 3/8 | 5 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Depressure drain | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) | |
| N100 204 112 100 | Y100204112100 | Request access | FR+L2 | 3/8 | 5 µm | 0÷2 Bar (29 psi) | 95,3 cmf (2700 Nl/Min) | Automatic with float | 4.882 (124) | 10.630 (270) | 2.638 (67) | 2.677 (68) | 1.535 (39) | 1.240 (31.5) | 5.098 (129.5) | 2.323 (59) | 4.764 (121) | 2.087 (53) | 1.634 (41.5) | 0.217 (5.5) | 1.575 (40) | E.D. 256 (6,5) | 6.240 (158.5) | 3/8 - 1/2 | 0.374 (9.5) | 2.854 (72.5) |
