Filter
0 = Without manual override
| Code | USA Ref | 3D Drawings | Version | Sealing material | Temperature | Port size - NPTF | Ø Orifice - inch (mm) | Viscosity (cSt) | Cv - gpm (Kv - m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - AC (7.5 VA) | OPD (ΔP) - AC (11 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| X4F 09 2 25 V 0 N | X4F09225V0N | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 09 2 25 N 0 N | X4F09225N0N | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 09 2 25 E 0 N | X4F09225E0N | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 07 2 18 V 0 N | X4F07218V0N | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 07 2 18 N 0 N | X4F07218N0N | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 07 2 18 E 0 N | X4F07218E0N | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 05 2 14 V 0 N | X4F05214V0N | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 05 2 14 N 0 N | X4F05214N0N | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 05 2 14 E 0 N | X4F05214E0N | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 04 2 14 V 0 N | X4F04214V0N | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 04 2 14 N 0 N | X4F04214N0N | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 04 2 14 E 0 N | X4F04214E0N | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 03 2 10 V 0 N | X4F03210V0N | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 03 2 10 N 0 N | X4F03210N0N | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 | |
| X4F 03 2 10 E 0 N | X4F03210E0N | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 1 |
