Filter
H = Without manual override
0 = With manual override
| Code | USA Ref | 3D Drawings | Version | Sealing material | Temperature | Port size - NPTF | Ø Orifice - inch (mm) | Viscosity (cSt) | Cv - gpm (Kv - m3/h) | OPD (ΔP) - DC (6.5 W) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - AC (7.5 VA) | OPD (ΔP) - AC (11 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| X4F 09 1 25 V H N | X4F09125VH | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 09 1 25 V 0 N | X4F09125V0 | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 09 1 25 N H N | X4F09125NH | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 09 1 25 N 0 N | X4F09125N0 | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 09 1 25 E H N | X4F09125EH | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 09 1 25 E 0 N | X4F09125E0 | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 07 1 18 V H N | X4F07118VH | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 07 1 18 V 0 N | X4F07118V0 | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 07 1 18 N H N | X4F07118NH | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 07 1 18 N 0 N | X4F07118N0 | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 07 1 18 E H N | X4F07118EH | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 07 1 18 E 0 N | X4F07118E0 | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 05 1 14 V H N | X4F05114VH | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 05 1 14 V 0 N | X4F05114V0 | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 05 1 14 N H N | X4F05114NH | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 05 1 14 N 0 N | X4F05114N0 | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 05 1 14 E H N | X4F05114EH | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 05 1 14 E 0 N | X4F05114E0 | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 1/2" | 35/64 (14) | 25 | 4.11 (3.53) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 04 1 14 V H N | X4F04114VH | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 04 1 14 V 0 N | X4F04114V0 | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 04 1 14 N H N | X4F04114NH | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 04 1 14 N 0 N | X4F04114N0 | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 04 1 14 E H N | X4F04114EH | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 04 1 14 E 0 N | X4F04114E0 | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 3/8" | 35/64 (14) | 25 | 3.87 (3.32) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 03 1 10 V H N | X4F03110VH | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 03 1 10 V 0 N | X4F03110V0 | Request access | 0 | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 03 1 10 N H N | X4F03110NH | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 03 1 10 N 0 N | X4F03110N0 | Request access | 0 | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 03 1 10 E H N | X4F03110EH | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| X4F 03 1 10 E 0 N | X4F03110E0 | Request access | 0 | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 2 - 232 psi (0.15 - 16 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 |
