Filter
| Code | USA Ref | 3D Drawings | Sealing material | Temperature | Port size NPT | DN Inch (mm) | Ø Orifice Inch (mm) | Viscosity (cSt) | Cv (gpm) | Actuator size Inch (mm) | Control pressure psi (bar) | OPD (ΔP) psi (bar) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| X1Y 04 1 040 0N | X1Y0410400N | Request access | PTFE | +14°F +356°F | 3/8" | .394 (10) | .512 (13) | 600 | 4.51 | 1.575 (40) | ≥ 58 (4) | 0 - 189 (13) | 1 | |
| X1Y 05 1 040 0N | X1Y0510400N | Request access | PTFE | +14°F +356°F | 1/2" | .591 (15) | .512 (13) | 600 | 4.97 | 1.575 (40) | ≥ 58 (4) | 0 - 189 (13) | 1 | |
| X1Y 07 1 050 0N | X1Y0710500N | Request access | PTFE | +14°F +356°F | 3/4" | .787 (20) | .709 (18) | 600 | 8.79 | 1.969 (50) | ≥ 65 (4.5) | 0 - 203 (14) | 1 | |
| X1Y 09 1 050 0N | X1Y0910500N | Request access | PTFE | +14°F +356°F | 1" | .984 (25) | .945 (24) | 600 | 18.26 | 1.969 (50) | ≥ 65 (4.5) | 0 - 116 (8) | 1 | |
| X1Y 09 1 063 0N | X1Y0910630N | Request access | PTFE | +14°F +356°F | 1" | .984 (25) | .945 (24) | 600 | 18.26 | 2.480 (63) | ≥ 73 (5) | 0 - 189 (13) | 1 | |
| X1Y XF 1 063 0N | X1YXF10630N | Request access | PTFE | +14°F +356°F | 1"1/4 | 1.260 (32) | 1.220 (31) | 600 | 30.06 | 2.480 (63) | ≥ 73 (5) | 0 - 87 (6) | 1 | |
| X1Y XF 1 090 0N | X1YXF10900N | Request access | PTFE | +14°F +356°F | 1"1/4 | 1.260 (32) | 1.220 (31) | 600 | 30.06 | 3.543 (90) | ≥ 87 (6) | 0 - 232 (16) | 1 | |
| X1Y XG 1 063 0N | X1YXG10630N | Request access | PTFE | +14°F +356°F | 1"1/2 | 1.575 (40) | 1.378 (35) | 600 | 36.99 | 2.480 (63) | ≥ 73 (5) | 0 - 73 (5) | 1 | |
| X1Y XG 1 090 0N | X1YXG10900N | Request access | PTFE | +14°F +356°F | 1"1/2 | 1.575 (40) | 1.378 (35) | 600 | 36.99 | 3.543 (90) | ≥ 87 (6) | 0 - 232 (16) | 1 | |
| X1Y XH 1 063 0N | X1YXH10630N | Request access | PTFE | +14°F +356°F | 2" | 1.969 (50) | 1.772 (45) | 600 | 60.11 | 2.480 (63) | ≥ 73 (5) | 0 - 29 (2) | 1 | |
| X1Y XH 1 090 0N | X1YXH10900N | Request access | PTFE | +14°F +356°F | 2" | 1.969 (50) | 1.772 (45) | 600 | 60.11 | 3.543 (90) | ≥ 87 (6) | 0 - 145 (10) | 1 |
