| Code | USA Ref | 3D Drawings | Sealing material | Temperature | Port size - NPTF | Ø Orifice IN/EXH - inch (mm) | Viscosity (cSt) | Cv IN/EXH - gpm (Kv IN/EXH - m3/h) | OPD (ΔP) - DC (4.6 W) | OPD (ΔP) - AC (6.8 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| X1C 02 3 15 N 0 N | X1C02315N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 1/16 - 1/16 (1.5 - 1.4) | 25 | 0.07 / 0.06 (0.06 / 0.05) | 0 - 137 psi (0 - 9.5 bar) | 0 - 137 psi (0 - 9.5 bar) | 1 | |
| X1C 02 3 15 V 0 N | X1C02315V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 1/16 - 1/16 (1.5 - 1.4) | 25 | 0.07 / 0.06 (0.06 / 0.05) | 0 - 137 psi (0 - 9.5 bar) | 0 - 137 psi (0 - 9.5 bar) | 1 | |
| X1C 02 3 15 E 0 N | X1C02315E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 1/16 - 1/16 (1.5 - 1.4) | 25 | 0.07 / 0.06 (0.06 / 0.05) | 0 - 137 psi (0 - 9.5 bar) | 0 - 137 psi (0 - 9.5 bar) | 1 | |
| X1C 02 3 02 N 0 N | X1C02302N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 5/64 - 1/16 (2 - 1.4) | 37 | 0.10 / 0.06 (0.09 / 0.05) | 0 - 72 psi (0 - 5 bar) | 0 - 72 psi (0 - 5 bar) | 1 | |
| X1C 02 3 02 V 0 N | X1C02302V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 5/64 - 1/16 (2 - 1.4) | 37 | 0.10 / 0.06 (0.09 / 0.05) | 0 - 72 psi (0 - 5 bar) | 0 - 72 psi (0 - 5 bar) | 1 | |
| X1C 02 3 02 E 0 N | X1C02302E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 5/64 - 1/16 (2 - 1.4) | 37 | 0.10 / 0.06 (0.09 / 0.05) | 0 - 72 psi (0 - 5 bar) | 0 - 72 psi (0 - 5 bar) | 1 | |
| X1C 02 3 25 N 0 N | X1C02325N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 3/32 - 1/16 (2.5 - 1.4) | 53 | 0.17 / 0.06 (0.15 / 0.05) | 0 - 43 psi (0 - 3 bar) | 0 - 43 psi (0 - 3 bar) | 1 | |
| X1C 02 3 25 V 0 N | X1C02325V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 3/32 - 1/16 (2.5 - 1.4) | 53 | 0.17 / 0.06 (0.15 / 0.05) | 0 - 43 psi (0 - 3 bar) | 0 - 43 psi (0 - 3 bar) | 1 | |
| X1C 02 3 25 E 0 N | X1C02325E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 3/32 - 1/16 (2.5 - 1.4) | 53 | 0.17 / 0.06 (0.15 / 0.05) | 0 - 43 psi (0 - 3 bar) | 0 - 43 psi (0 - 3 bar) | 1 | |
| X1C 03 3 15 N 0 N | X1C03315N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 1/16 - 1/16 (1.5 - 1.4) | 25 | 0.07 / 0.06 (0.06 / 0.05) | 0 - 137 psi (0 - 9.5 bar) | 0 - 137 psi (0 - 9.5 bar) | 1 | |
| X1C 03 3 15 V 0 N | X1C03315V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/16 - 1/16 (1.5 - 1.4) | 25 | 0.07 / 0.06 (0.06 / 0.05) | 0 - 137 psi (0 - 9.5 bar) | 0 - 137 psi (0 - 9.5 bar) | 1 | |
| X1C 03 3 15 E 0 N | X1C03315E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/16 - 1/16 (1.5 - 1.4) | 25 | 0.07 / 0.06 (0.06 / 0.05) | 0 - 137 psi (0 - 9.5 bar) | 0 - 137 psi (0 - 9.5 bar) | 1 | |
| X1C 03 3 02 N 0 N | X1C03302N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 5/64 - 1/16 (2 - 1.4) | 37 | 0.10 / 0.06 (0.09 / 0.05) | 0 - 72 psi (0 - 5 bar) | 0 - 72 psi (0 - 5 bar) | 1 | |
| X1C 03 3 02 V 0 N | X1C03302V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/64 - 1/16 (2 - 1.4) | 37 | 0.10 / 0.06 (0.09 / 0.05) | 0 - 72 psi (0 - 5 bar) | 0 - 72 psi (0 - 5 bar) | 1 | |
| X1C 03 3 02 E 0 N | X1C03302E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/64 - 1/16 (2 - 1.4) | 37 | 0.10 / 0.06 (0.09 / 0.05) | 0 - 72 psi (0 - 5 bar) | 0 - 72 psi (0 - 5 bar) | 1 | |
| X1C 03 3 25 N 0 N | X1C03325N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 3/32 - 1/16 (2.5 - 1.4) | 53 | 0.17 / 0.06 (0.15 / 0.05) | 0 - 43 psi (0 - 3 bar) | 0 - 43 psi (0 - 3 bar) | 1 | |
| X1C 03 3 25 V 0 N | X1C03325V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 3/32 - 1/16 (2.5 - 1.4) | 53 | 0.17 / 0.06 (0.15 / 0.05) | 0 - 43 psi (0 - 3 bar) | 0 - 43 psi (0 - 3 bar) | 1 | |
| X1C 03 3 25 E 0 N | X1C03325E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 3/32 - 1/16 (2.5 - 1.4) | 53 | 0.17 / 0.06 (0.15 / 0.05) | 0 - 43 psi (0 - 3 bar) | 0 - 43 psi (0 - 3 bar) | 1 |
