Filter
| Code | USA Ref | 3D Drawings | Sealing material | Temperature | Port size | Ø Orifice IN/EXH - inch (mm) | Viscosity (cSt) | Cv IN/EXH - gpm (Kv IN/EXH - m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - DC (14 W) | OPD (ΔP) - DC (22 W) | OPD (ΔP) - AC (14 VA) | OPD (ΔP) - AC (21 VA) | OPD (ΔP) - AC (31 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| F2F J9 3 15 N 0 | Request access | NBR | +14°F +194°F (-10°C +90°C) | Flange 32x32 mm | 1/16 - 3/32 (1.5 - 2.3) | 25 | 0.07 - 0.15 (0.06 - 0.13) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 1 | ||
| F2F J9 3 15 V 0 | Request access | FKM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 1/16 - 3/32 (1.5 - 2.3) | 25 | 0.07 - 0.15 (0.06 - 0.13) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 1 | ||
| F2F J9 3 15 E 0 | Request access | EPDM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 1/16 - 3/32 (1.5 - 2.3) | 25 | 0.07 - 0.15 (0.06 - 0.13) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 1 | ||
| F2F J9 3 15 R 3 | Request access | RUBY | -40°F +356°F (-40°C +180°C) | Flange 32x32 mm | 1/16 - 3/32 (1.5 - 2.3) | 25 | 0.07 - 0.15 (0.06 - 0.13) | 0 - 218 psi (0 - 15 bar) | 0 - 218 psi (0 - 15 bar) | 0 - 218 psi (0 - 15 bar) | 0 - 218 psi (0 - 15 bar) | 0 - 218 psi (0 - 15 bar) | 0 - 218 psi (0 - 15 bar) | 1 | ||
| F2F J9 3 15 C 0 | Request access | CR | -31°F +212°F (-35°C +100°C) | Flange 32x32 mm | 1/16 - 3/32 (1.5 - 2.3) | 25 | 0.07 - 0.15 (0.06 - 0.13) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 1 | ||
| F2F J9 3 02 N 0 | Request access | NBR | +14°F +194°F (-10°C +90°C) | Flange 32x32 mm | 5/64 - 3/32 (2 - 2.3) | 37 | 0.12 - 0.15 (0.10 - 0.13) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | ||
| F2F J9 3 02 V 0 | Request access | FKM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 5/64 - 3/32 (2 - 2.3) | 37 | 0.12 - 0.15 (0.10 - 0.13) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | ||
| F2F J9 3 02 E 0 | Request access | EPDM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 5/64 - 3/32 (2 - 2.3) | 37 | 0.12 - 0.15 (0.10 - 0.13) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | ||
| F2F J9 3 02 R 3 | Request access | RUBY | -40°F +356°F (-40°C +180°C) | Flange 32x32 mm | 5/64 - 3/32 (2 - 2.3) | 37 | 0.12 - 0.15 (0.10 - 0.13) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | ||
| F2F J9 3 02 C 0 | Request access | CR | -31°F +212°F (-35°C +100°C) | Flange 32x32 mm | 5/64 - 3/32 (2 - 2.3) | 37 | 0.12 - 0.15 (0.10 - 0.13) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | ||
| F2F J9 3 25 N 0 | Request access | NBR | +14°F +194°F (-10°C +90°C) | Flange 32x32 mm | 3/32 - 3/32 (2.5 - 2.3) | 37 | 0.17 - 0.15 (0.15 - 0.13) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 1 | ||
| F2F J9 3 25 V 0 | Request access | FKM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 3/32 - 3/32 (2.5 - 2.3) | 37 | 0.17 - 0.15 (0.15 - 0.13) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 1 | ||
| F2F J9 3 25 E 0 | Request access | EPDM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 3/32 - 3/32 (2.5 - 2.3) | 37 | 0.17 - 0.15 (0.15 - 0.13) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 1 | ||
| F2F J9 3 25 R 3 | Request access | RUBY | -40°F +356°F (-40°C +180°C) | Flange 32x32 mm | 3/32 - 3/32 (2.5 - 2.3) | 37 | 0.17 - 0.15 (0.15 - 0.13) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | ||
| F2F J9 3 25 C 0 | Request access | CR | -31°F +212°F (-35°C +100°C) | Flange 32x32 mm | 3/32 - 3/32 (2.5 - 2.3) | 37 | 0.17 - 0.15 (0.15 - 0.13) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 1 | ||
| F2F J9 3 03 N 0 | Request access | NBR | +14°F +194°F (-10°C +90°C) | Flange 32x32 mm | 1/8 - 3/32 (3 - 2.3) | 37 | 0.24 - 0.15 (0.21 - 0.13) | - | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | ||
| F2F J9 3 03 V 0 | Request access | FKM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 1/8 - 3/32 (3 - 2.3) | 37 | 0.24 - 0.15 (0.21 - 0.13) | - | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | ||
| F2F J9 3 03 E 0 | Request access | EPDM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 1/8 - 3/32 (3 - 2.3) | 37 | 0.24 - 0.15 (0.21 - 0.13) | - | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | ||
| F2F J9 3 03 C 0 | Request access | CR | -31°F +212°F (-35°C +100°C) | Flange 32x32 mm | 1/8 - 3/32 (3 - 2.3) | 37 | 0.24 - 0.15 (0.21 - 0.13) | - | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | ||
| F2F J9 3 04 N 0 | Request access | NBR | +14°F +194°F (-10°C +90°C) | Flange 32x32 mm | 5/32 - 3/32 (4 - 2.3) | 37 | 0.41 - 0.15 (0.35 - 0.13) | - | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | ||
| F2F J9 3 04 V 0 | Request access | FKM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 5/32 - 3/32 (4 - 2.3) | 37 | 0.41 - 0.15 (0.35 - 0.13) | - | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | ||
| F2F J9 3 04 E 0 | Request access | EPDM | +14°F +284°F (-10°C +140°C) | Flange 32x32 mm | 5/32 - 3/32 (4 - 2.3) | 37 | 0.41 - 0.15 (0.35 - 0.13) | - | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | ||
| F2F J9 3 04 C 0 | Request access | CR | -31°F +212°F (-35°C +100°C) | Flange 32x32 mm | 5/32 - 3/32 (4 - 2.3) | 37 | 0.41 - 0.15 (0.35 - 0.13) | - | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 |
