| Code | USA Ref | 3D Drawings | Sealing material | Temperature | Port size | Ø Orifice - inch (mm) | Viscosity (cSt) | Cv - gpm (Kv - m3/h) | OPD (ΔP) - DC (2 W) | OPD (ΔP) - DC (3 W) | OPD (ΔP) - DC (4 W) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| F1F J4 B 15 N 0 | F1FJ4B15N0 | Request access | NBR | +14°F +194 °F (-10°C +90°C) | Flange 25x25 mm | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 0 - 578 psi (0 - 35 bar) | 1 | |
| F1F J4 B 15 V 0 | F1FJ4B15V0 | Request access | FKM | +14°F +284°F (-10°C +140°C) | Flange 25x25 mm | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 0 - 578 psi (0 - 35 bar) | 1 | |
| F1F J4 B 15 E 0 | F1FJ4B15E0 | Request access | EPDM | +14°F +284°F (-10°C +140°C) | Flange 25x25 mm | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 0 - 578 psi (0 - 35 bar) | 1 | |
| F1F J4 B 15 C 0 | F1FJ4B15C0 | Request access | CR | -31°F +212°F (-35°C +100°C) | Flange 25x25 mm | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 0 - 578 psi (0 - 35 bar) | 1 | |
| F1F J4 B 02 N 0 | F1FJ4B02N0 | Request access | NBR | +14°F +194 °F (-10°C +90°C) | Flange 25x25 mm | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 94 psi (0 - 6.5 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 334 psi (0 - 23 bar) | 1 | |
| F1F J4 B 02 V 0 | F1FJ4B02V0 | Request access | FKM | +14°F +284°F (-10°C +140°C) | Flange 25x25 mm | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 94 psi (0 - 6.5 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 334 psi (0 - 23 bar) | 1 | |
| F1F J4 B 02 E 0 | F1FJ4B02E0 | Request access | EPDM | +14°F +284°F (-10°C +140°C) | Flange 25x25 mm | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 94 psi (0 - 6.5 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 334 psi (0 - 23 bar) | 1 | |
| F1F J4 B 02 C 0 | F1FJ4B02C0 | Request access | CR | -31°F +212°F (-35°C +100°C) | Flange 25x25 mm | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 94 psi (0 - 6.5 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 334 psi (0 - 23 bar) | 1 | |
| F1F J4 B 25 N 0 | F1FJ4B25N0 | Request access | NBR | +14°F +194 °F (-10°C +90°C) | Flange 25x25 mm | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 36 psi (0 - 2.5 bar) | 0 - 334 psi (0 - 23 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| F1F J4 B 25 V 0 | F1FJ4B25V0 | Request access | FKM | +14°F +284°F (-10°C +140°C) | Flange 25x25 mm | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 36 psi (0 - 2.5 bar) | 0 - 334 psi (0 - 23 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| F1F J4 B 25 E 0 | F1FJ4B25E0 | Request access | EPDM | +14°F +284°F (-10°C +140°C) | Flange 25x25 mm | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 36 psi (0 - 2.5 bar) | 0 - 334 psi (0 - 23 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| F1F J4 B 25 C 0 | F1FJ4B25C0 | Request access | CR | -31°F +212°F (-35°C +100°C) | Flange 25x25 mm | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 36 psi (0 - 2.5 bar) | 0 - 334 psi (0 - 23 bar) | 0 - 145 psi (0 - 10 bar) | 1 |
