Filter
T = Without manual override
| Code | USA Ref | 3D Drawings | Version | Sealing material | Temperature | Port size - NPTF | Ø Orifice - inch (mm) | Viscosity (cSt) | Cv - gpm (Kv - m3/h) | OPD (ΔP) - DC (2 W) | OPD (ΔP) - DC (3 W) | OPD (ΔP) - DC (4 W) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 04F 09 B 25 V T N | 04F09B25VTN | Request access | T | FKM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 09 B 25 V T N | 04F09B25VTN | Request access | T | FKM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 09 B 25 N T N | 04F09B25NTN | Request access | T | NBR | +14°F +194 °F (-10°C +90°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 09 B 25 N T N | 04F09B25NTN | Request access | T | NBR | +14°F +194 °F (-10°C +90°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 09 B 25 E T N | 04F09B25ETN | Request access | T | EPDM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 09 B 25 E T N | 04F09B25ETN | Request access | T | EPDM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 V T N | 04F07B18VTN | Request access | T | FKM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64(18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 V T N | 04F07B18VTN | Request access | T | FKM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64(18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 N T N | 04F07B18NTN | Request access | T | NBR | +14°F +194 °F (-10°C +90°C) | 3/4" | 45/64(18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 N T N | 04F07B18NTN | Request access | T | NBR | +14°F +194 °F (-10°C +90°C) | 3/4" | 45/64(18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 E T N | 04F07B18ETN | Request access | T | EPDM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64(18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 E T N | 04F07B18ETN | Request access | T | EPDM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64(18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 |
