1 = Without manual override
3 = Without manual override and with reinforced and guided diaphgram
| Code | USA Ref | 3D Drawings | Version | Sealing material | Temperature | Port size - NPTF | Ø Orifice - inch (mm) | Viscosity (cSt) | Cv - gpm (Kv - m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - AC (7.5 VA) | OPD (ΔP) - AC (11 VA) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 04F 07 2 18 N 1 N | 04F07218N1N | Request access | 1 | NBR | +14°F +194 °F (-10°C +90°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 07 2 18 V 1 N | 04F07218V1N | Request access | 1 | FKM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 07 2 18 E 1 N | 04F07218E1N | Request access | 1 | EPDM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 09 2 25 N 1 N | 04F09225N1N | Request access | 1 | NBR | +14°F +194 °F (-10°C +90°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 09 2 25 V 1 N | 04F09225V1N | Request access | 1 | FKM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 09 2 25 E 1 N | 04F09225E1N | Request access | 1 | EPDM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 07 2 18 N 3 N | 04F07218N3N | Request access | 3 | NBR | +14°F +194 °F (-10°C +90°C) | 3/4" | 45/64 (18) | 25 | 5.72 (4.91) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 07 2 18 V 3 N | 04F07218V3N | Request access | 3 | FKM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 5.72 (4.91) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 07 2 18 E 3 N | 04F07218E3N | Request access | 3 | EPDM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 5.72 (4.91) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 09 2 25 N 3 N | 04F09225N3N | Request access | 3 | NBR | +14°F +194 °F (-10°C +90°C) | 1" | 1 (25) | 25 | 10.86 (9.32) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 09 2 25 V 3 N | 04F09225V3N | Request access | 3 | FKM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 10.86 (9.32) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | |
| 04F 09 2 25 E 3 N | 04F09225E3N | Request access | 3 | EPDM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 10.86 (9.32) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) | 2 - 145 psi (0.15 - 10 bar) |
