Filter
1 = Without manual override
| Code | USA Ref | 3D Drawings | Version | Sealing material | Temperature | Port size | Ø Orifice - inch (mm) | Viscosity (cSt) | Kv (m3/h) | OPD (ΔP) - DC (14 W) | OPD (ΔP) - DC (22 W) | OPD (ΔP) - AC (14 VA) | OPD (ΔP) - AC (21 VA) | OPD (ΔP) - AC (31 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 04F XF 2 40 N 1 N | 04FXF240N1N | Request access | 1 | NBR | +14°F +194°F (-10°C +90°C) | 1"1/4 | 1" 9/16 (40) | 25 | 27.74 (24) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 | |
| 04F XF 2 40 V 1 N | 04FXF240V1N | Request access | 1 | FKM | +14°F +284°F (-10°C +140°C) | 1"1/4 | 1" 9/16 (40) | 25 | 27.74 (24) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 | |
| 04F XF 2 40 E 1 N | 04FXF240E1N | Request access | 1 | EPDM | +14°F +284°F (-10°C +140°C) | 1"1/4 | 1" 9/16 (40) | 25 | 27.74 (24) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 | |
| 04F XG 2 40 N 1 N | 04FXG240N1N | Request access | 1 | NBR | +14°F +194°F (-10°C +90°C) | 1"1/2 | 1" 9/16 (40) | 25 | 29.2 (25.3) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 | |
| 04F XG 2 40 V 1 N | 04FXG240V1N | Request access | 1 | FKM | +14°F +284°F (-10°C +140°C) | 1"1/2 | 1" 9/16 (40) | 25 | 29.2 (25.3) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 | |
| 04F XG 2 40 E 1 N | 04FXG240E1N | Request access | 1 | EPDM | +14°F +284°F (-10°C +140°C) | 1"1/2 | 1" 9/16 (40) | 25 | 29.2 (25.3) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 | |
| 04F XH 2 50 N 1 N | 04FXH250N1N | Request access | 1 | NBR | +14°F +194°F (-10°C +90°C) | 2" | 1" 61/64 (50) | 25 | 47.39 (41) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 | |
| 04F XH 2 50 V 1 N | 04FXH250V1N | Request access | 1 | FKM | +14°F +284°F (-10°C +140°C) | 2" | 1" 61/64 (50) | 25 | 47.39 (41) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 | |
| 04F XH 2 50 E 1 N | 04FXH250E1N | Request access | 1 | EPDM | +14°F +284°F (-10°C +140°C) | 2" | 1" 61/64 (50) | 25 | 47.39 (41) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 2.9 - 145 psi (0.20 - 10 bar) | 1 |
