Filter
H = Without manual override
| Code | USA Ref | 3D Drawings | Version | Sealing material | Temperature | Port size - NPTF | Ø Orifice - inch (mm) | Viscosity (cSt) | Cv - gpm (Kv - m3/h) | OPD (ΔP) - DC (2 W) | OPD (ΔP) - DC (3 W) | OPD (ΔP) - DC (4 W) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 04F 09 B 25 V H N | 04F09B25VHN | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 09 B 25 N H N | 04F09B25NHN | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 09 B 25 E H N | 04F09B25EHN | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 1" | 1 (25) | 25 | 12.78 (10.97) | 2 - 79 psi (0.15 - 5.5 bar) | 2 - 123 psi (0.15 - 8.5 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 V H N | 04F07B18VHN | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 N H N | 04F07B18NHN | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 07 B 18 E H N | 04F07B18EHN | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 3/4" | 45/64 (18) | 25 | 6.48 (5.56) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 05 B 14 V H N | 04F05B14VHN | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 1/2" | 15/32 (12) | 25 | 3.53 (3.03) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 05 B 14 N H N | 04F05B14NHN | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 1/2" | 15/32 (12) | 25 | 3.53 (3.03) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 05 B 14 E H N | 04F05B14EHN | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 1/2" | 15/32 (12) | 25 | 3.53 (3.03) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 04 B 14 V H N | 04F04B14VHN | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 3/8" | 15/32 (12) | 25 | 3.38 (2.90) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 04 B 14 N H N | 04F04B14NHN | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 3/8" | 15/32 (12) | 25 | 3.38 (2.90) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 04 B 14 E H N | 04F04B14EHN | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 3/8" | 15/32 (12) | 25 | 3.38 (2.90) | 2 - 87 psi (0.15 - 6 bar) | 2 - 174 psi (0.15 - 12 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 03 B 10 V H N | 04F03B10VHN | Request access | H | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 94 psi (0.15 - 6.5 bar) | 2 - 188 psi (0.15 - 13 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 03 B 10 N H N | 04F03B10NHN | Request access | H | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 94 psi (0.15 - 6.5 bar) | 2 - 188 psi (0.15 - 13 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 | |
| 04F 03 B 10 E H N | 04F03B10EHN | Request access | H | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 25/64 (10) | 25 | 2.19 (1.88) | 2 - 94 psi (0.15 - 6.5 bar) | 2 - 188 psi (0.15 - 13 bar) | 2 - 261 psi (0.15 - 18 bar) | 1 |
