| Code | USA Ref | 3D Drawings | Sealing material | Temperature | Port size - NPTF | Ø Orifice IN/EXH - inch (mm) | Viscosity (cSt) | Cv IN/EXH - gpm (Kv IN/EXH - m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - DC (14 W) | OPD (ΔP) - DC (22 W) | OPD (ΔP) - AC (14 VA) | OPD (ΔP) - AC (21 VA) | OPD (ΔP) - AC (31 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02F 05 3 05 V 0 N | 02F05305V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/2" | 13/64 - 5/64 (5 - 1.9 ) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 05 3 05 N 0 N | 02F05305N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/2" | 13/64 - 5/64 (5 - 1.9 ) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 05 3 05 E 0 N | 02F05305E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/2" | 13/64 - 5/64 (5 - 1.9 ) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 05 3 05 C 0 N | 02F05305C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/2" | 13/64 - 5/64 (5 - 1.9 ) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 05 3 04 V 0 N | 02F05304V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/2" | 5/32 - 5/64 (4 - 1.9 ) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 05 3 04 N 0 N | 02F05304N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/2" | 5/32 - 5/64 (4 - 1.9 ) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 05 3 04 E 0 N | 02F05304E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/2" | 5/32 - 5/64 (4 - 1.9 ) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 05 3 04 C 0 N | 02F05304C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/2" | 5/32 - 5/64 (4 - 1.9 ) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 05 3 03 V 0 N | 02F05303V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/2" | 1/8 - 5/64 (3 - 1.9 ) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 05 3 03 N 0 N | 02F05303N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/2" | 1/8 - 5/64 (3 - 1.9 ) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 05 3 03 E 0 N | 02F05303E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/2" | 1/8 - 5/64 (3 - 1.9 ) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 05 3 03 C 0 N | 02F05303C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/2" | 1/8 - 5/64 (3 - 1.9 ) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 04 3 05 V 0 N | 02F04305V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 3/8" | 13/64 - 5/64 (5 - 1.9 ) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 04 3 05 N 0 N | 02F04305N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 3/8" | 13/64 - 5/64 (5 - 1.9 ) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 04 3 05 E 0 N | 02F04305E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 3/8" | 13/64 - 5/64 (5 - 1.9 ) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 04 3 05 C 0 N | 02F04305C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 3/8" | 13/64 - 5/64 (5 - 1.9 ) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 04 3 04 V 0 N | 02F04304V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 3/8" | 5/32 - 5/64 (4 - 1.9 ) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 04 3 04 N 0 N | 02F04304N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 3/8" | 5/32 - 5/64 (4 - 1.9 ) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 04 3 04 E 0 N | 02F04304E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 3/8" | 5/32 - 5/64 (4 - 1.9 ) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 04 3 04 C 0 N | 02F04304C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 3/8" | 5/32 - 5/64 (4 - 1.9 ) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 04 3 03 V 0 N | 02F04303V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 3/8" | 1/8 - 5/64 (3 - 1.9 ) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 04 3 03 N 0 N | 02F04303N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 3/8" | 1/8 - 5/64 (3 - 1.9 ) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 04 3 03 E 0 N | 02F04303E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 3/8" | 1/8 - 5/64 (3 - 1.9 ) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 04 3 03 C 0 N | 02F04303C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 3/8" | 1/8 - 5/64 (3 - 1.9 ) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 |
