Filter
| Code | USA Ref | 3D Drawings | Sealing material | Temperature | Port size - NPTF | Ø Orifice IN/EXH - inch (mm) | Viscosity (cSt) | Cv IN/EXH - gpm (Kv IN/EXH - m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - DC (14 W) | OPD (ΔP) - DC (22 W) | OPD (ΔP) - AC (14 VA) | OPD (ΔP) - AC (21 VA) | OPD (ΔP) - AC (31 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02F 03 3 25 V 0 N | 02F03325V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 3/32 - 5/64 (2.5 - 1.9) | 37 | 0.17 - 0.12 (0.15 - 0.10) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 1 | |
| 02F 03 3 25 N 0 N | 02F03325N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 3/32 - 5/64 (2.5 - 1.9) | 37 | 0.17 - 0.12 (0.15 - 0.10) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 1 | |
| 02F 03 3 25 E 0 N | 02F03325E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 3/32 - 5/64 (2.5 - 1.9) | 37 | 0.17 - 0.12 (0.15 - 0.10) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 1 | |
| 02F 03 3 25 C 0 N | 02F03325C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 3/32 - 5/64 (2.5 - 1.9) | 37 | 0.17 - 0.12 (0.15 - 0.10) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 0 - 189 psi (0 - 13 bar) | 1 | |
| 02F 03 3 15 V 0 N | 02F03315V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/16 - 5/64 (1.5 - 1.9) | 25 | 0.07 - 0.12 (0.06 - 0.10) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 1 | |
| 02F 03 3 15 N 0 N | 02F03315N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 1/16 - 5/64 (1.5 - 1.9) | 25 | 0.07 - 0.12 (0.06 - 0.10) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 1 | |
| 02F 03 3 15 E 0 N | 02F03315E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/16 - 5/64 (1.5 - 1.9) | 25 | 0.07 - 0.12 (0.06 - 0.10) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 1 | |
| 02F 03 3 15 C 0 N | 02F03315C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 1/16 - 5/64 (1.5 - 1.9) | 25 | 0.07 - 0.12 (0.06 - 0.10) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 0 - 363 psi (0 - 25 bar) | 1 | |
| 02F 03 3 05 V 0 N | 02F03305V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 13/64 - 5/64 (5 - 1.9) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 03 3 05 N 0 N | 02F03305N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 13/64 - 5/64 (5 - 1.9) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 03 3 05 E 0 N | 02F03305E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 13/64 - 5/64 (5 - 1.9) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 03 3 05 C 0 N | 02F03305C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 13/64 - 5/64 (5 - 1.9) | 37 | 0.59 - 0.12 (0.51 - 0.10) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 0 - 44 psi (0 - 3 bar) | 1 | |
| 02F 03 3 04 V 0 N | 02F03304V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/32 - 5/64 (4 - 1.9) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 03 3 04 N 0 N | 02F03304N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 5/32 - 5/64 (4 - 1.9) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 03 3 04 E 0 N | 02F03304E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/32 - 5/64 (4 - 1.9) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 03 3 04 C 0 N | 02F03304C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 5/32 - 5/64 (4 - 1.9) | 37 | 0.41 - 0.12 (0.35 - 0.10) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 0 - 87 psi (0 - 6 bar) | 1 | |
| 02F 03 3 03 V 0 N | 02F03303V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/8 - 5/64 (3 - 1.9) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 03 3 03 N 0 N | 02F03303N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 1/8 - 5/64 (3 - 1.9) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 03 3 03 E 0 N | 02F03303E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/8 - 5/64 (3 - 1.9) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 03 3 03 C 0 N | 02F03303C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 1/8 - 5/64 (3 - 1.9) | 37 | 0.24 - 0.12 (0.21 - 0.10) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 02F 03 3 02 V 0 N | 02F03302V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/64 - 5/64 (2 - 1.9) | 37 | 0.12 - 0.12 (0.10 - 0.10) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 02F 03 3 02 N 0 N | 02F03302N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 5/64 - 5/64 (2 - 1.9) | 37 | 0.12 - 0.12 (0.10 - 0.10) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 02F 03 3 02 E 0 N | 02F03302E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/64 - 5/64 (2 - 1.9) | 37 | 0.12 - 0.12 (0.10 - 0.10) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 02F 03 3 02 C 0 N | 02F03302C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 5/64 - 5/64 (2 - 1.9) | 37 | 0.12 - 0.12 (0.10 - 0.10) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 |
