| Code | USA Ref | 3D Drawings | Sealing material | Temperature | Port size - NPTF | Ø Orifice - inch (mm) | Viscosity (cSt) | Cv - gpm (Kv - m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - AC (7.5 VA) | OPD (ΔP) - AC (11 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 01F 02 2 15 N 0 N | 01F02215N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 01F 02 2 15 V 0 N | 01F02215V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 01F 02 2 15 E 0 N | 01F02215E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 01F 02 2 15 C 0 N | 01F02215C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/8" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 01F 02 2 02 N 0 N | 01F02202N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 01F 02 2 02 V 0 N | 01F02202V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 01F 02 2 02 E 0 N | 01F02202E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 01F 02 2 02 C 0 N | 01F02202C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/8" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 01F 02 2 25 N 0 N | 01F02225N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 3/32(2.5) | 53 | 0.17 (0.15) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 1 | |
| 01F 02 2 25 V 0 N | 01F02225V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 3/32(2.5) | 53 | 0.17 (0.15) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 1 | |
| 01F 02 2 25 E 0 N | 01F02225E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 3/32(2.5) | 53 | 0.17 (0.15) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 1 | |
| 01F 02 2 25 C 0 N | 01F02225C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/8" | 3/32(2.5) | 53 | 0.17 (0.15) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 1 | |
| 01F 02 2 03 N 0 N | 01F02203N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 1/8 (3) | 53 | 0.23 (0.2) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 1 | |
| 01F 02 2 03 V 0 N | 01F02203V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 1/8 (3) | 53 | 0.23 (0.2) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 1 | |
| 01F 02 2 03 E 0 N | 01F02203E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 1/8 (3) | 53 | 0.23 (0.2) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 1 | |
| 01F 02 2 03 C 0 N | 01F02203C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/8" | 1/8 (3) | 53 | 0.23 (0.2) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 1 | |
| 01F 03 2 15 N 0 N | 01F03215N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 01F 03 2 15 V 0 N | 01F03215V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 01F 03 2 15 E 0 N | 01F03215E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 01F 03 2 15 C 0 N | 01F03215C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 0 - 261 psi (0 - 18 bar) | 1 | |
| 01F 03 2 02 N 0 N | 01F03202N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 01F 03 2 02 V 0 N | 01F03202V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 01F 03 2 02 E 0 N | 01F03202E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 01F 03 2 02 C 0 N | 01F03202C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 0 - 145 psi (0 - 10 bar) | 1 | |
| 01F 03 2 25 N 0 N | 01F03225N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 3/32(2.5) | 53 | 0.17 (0.15) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 1 | |
| 01F 03 2 25 V 0 N | 01F03225V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 3/32(2.5) | 53 | 0.17 (0.15) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 1 | |
| 01F 03 2 25 E 0 N | 01F03225E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 3/32(2.5) | 53 | 0.17 (0.15) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 1 | |
| 01F 03 2 25 C 0 N | 01F03225C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 3/32(2.5) | 53 | 0.17 (0.15) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 0 - 94 psi (0 - 6.5 bar) | 1 | |
| 01F 03 2 03 N 0 N | 01F03203N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 1/8 (3) | 53 | 0.23 (0.2) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 1 | |
| 01F 03 2 03 V 0 N | 01F03203V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/8 (3) | 53 | 0.23 (0.2) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 1 | |
| 01F 03 2 03 E 0 N | 01F03203E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/8 (3) | 53 | 0.23 (0.2) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 1 | |
| 01F 03 2 03 C 0 N | 01F03203C0N | Request access | CR | -31°F +212°F (-35°C +100°C) | 1/4" | 1/8 (3) | 53 | 0.23 (0.2) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 0 - 61 psi (0 - 4.2 bar) | 1 |
