Filter
| Code | USA Ref | 3D Drawings | Sealing material | Temperature | Port size - NPTF | Ø Orifice - inch (mm) | Viscosity (cSt) | Cv - gpm (Kv - m3/h) | OPD (ΔP) - DC (4.6 W) | OPD (ΔP) - AC (6.8 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 01C 03 1 25 V 0 N | 01C03125V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 1 | |
| 01C 03 1 25 N 0 N | 01C03125N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 1 | |
| 01C 03 1 25 E 0 N | 01C03125E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 1 | |
| 01C 03 1 15 V 0 N | 01C03115V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 580 psi (0 - 40 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 03 1 15 N 0 N | 01C03115N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 580 psi (0 - 40 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 03 1 15 E 0 N | 01C03115E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 580 psi (0 - 40 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 03 1 02 V 0 N | 01C03102V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 435 psi (0 - 30 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 03 1 02 N 0 N | 01C03102N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/4" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 435 psi (0 - 30 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 03 1 02 E 0 N | 01C03102E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/4" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 435 psi (0 - 30 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 02 1 25 V 0 N | 01C02125V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 1 | |
| 01C 02 1 25 N 0 N | 01C02125N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 1 | |
| 01C 02 1 25 E 0 N | 01C02125E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 3/32 (2.5) | 53 | 0.17 (0.15) | 0 - 145 psi (0 - 10 bar) | 0 - 290 psi (0 - 20 bar) | 1 | |
| 01C 02 1 15 V 0 N | 01C02115V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 580 psi (0 - 40 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 02 1 15 N 0 N | 01C02115N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 580 psi (0 - 40 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 02 1 15 E 0 N | 01C02115E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 1/16 (1.5) | 25 | 0.07 (0.06) | 0 - 580 psi (0 - 40 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 02 1 02 V 0 N | 01C02102V0N | Request access | FKM | +14°F +284°F (-10°C +140°C) | 1/8" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 435 psi (0 - 30 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 02 1 02 N 0 N | 01C02102N0N | Request access | NBR | +14°F +194°F (-10°C +90°C) | 1/8" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 435 psi (0 - 30 bar) | 0 - 580 psi (0 - 40 bar) | 1 | |
| 01C 02 1 02 E 0 N | 01C02102E0N | Request access | EPDM | +14°F +284°F (-10°C +140°C) | 1/8" | 5/64 (2) | 37 | 0.1 (0.09) | 0 - 435 psi (0 - 30 bar) | 0 - 580 psi (0 - 40 bar) | 1 |
