| Code | USA Ref | 3D Drawings | Ways | Type of Connection | Function | Solenoid | * | IP | Pack | |
|---|---|---|---|---|---|---|---|---|---|---|
| 07V 11 3 NC 01 | 07V113NC01 | Request access | 3/2 | Line Connector + LED | NC | 24V DC | Item integrated with surge protector. | IP50 | 1 | |
| 07V 11 3 NC 00 | 07V113NC00 | Request access | 3/2 | Line Connector + LED | NC | 12V DC | Item integrated with surge protector. | IP50 | 1 | |
| 07V 11 3 NO 01 | 07V113NO01 | Request access | 3/2 | Line Connector + LED | NO | 24V DC | Item integrated with surge protector. | IP50 | 1 | |
| 07V 11 3 NO 00 | 07V113NO00 | Request access | 3/2 | Line Connector + LED | NO | 12V DC | Item integrated with surge protector. | IP50 | 1 | |
| 07V 12 3 NC 01 | 07V123NC01 | Request access | 3/2 | 90° Connector + LED | NC | 24V DC | Item integrated with surge protector. | IP50 | 1 | |
| 07V 12 3 NC 00 | 07V123NC00 | Request access | 3/2 | 90° Connector + LED | NC | 12V DC | Item integrated with surge protector. | IP50 | 1 | |
| 07V 12 3 NO 01 | 07V123NO01 | Request access | 3/2 | 90° Connector + LED | NO | 24V DC | Item integrated with surge protector. | IP50 | 1 | |
| 07V 12 3 NO 00 | 07V123NO00 | Request access | 3/2 | 90° Connector + LED | NO | 12V DC | Item integrated with surge protector. | IP50 | 1 | |
| 07V 13 3 NC 01 | 07V133NC01 | Request access | 3/2 | Cable (300 mm) | NC | 24V DC | IP65 | 1 | ||
| 07V 13 3 NC 00 | 07V133NC00 | Request access | 3/2 | Cable (300 mm) | NC | 12V DC | IP65 | 1 | ||
| 07V 13 3 NO 01 | 07V133NO01 | Request access | 3/2 | Cable (300 mm) | NO | 24V DC | IP65 | 1 | ||
| 07V 13 3 NO 00 | 07V133NO00 | Request access | 3/2 | Cable (300 mm) | NO | 12V DC | IP65 | 1 |
