Filter
| Code | 3D-Zeichnungen | Nummer | Dichtungswerkstoffe | Temperatur | Verbindungen | Ø Dn - IN/EXH (mm) | Viskosität (cSt) | Kv - IN/EXH (m3/h) | OPD (ΔP) - DC (6.5 W) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - AC (7.5 VA) | OPD (ΔP) - AC (11 VA) | OPD (ΔP) - DC (5.3 W) - Atex Ex m | OPD (ΔP) - AC (5.3 W) - Atex Ex m | Verpackung | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| F1FJ4315N0 | Zugang anfordern | F1F J4 3 15 N 0 | NBR | -10°C +90°C | Flansch 25x25 mm | 1.5 / 1.4 | 25 | 0.06 / 0.05 | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 1 | |
| F1FJ4315V0 | Zugang anfordern | F1F J4 3 15 V 0 | FKM | -10°C +140°C | Flansch 25x25 mm | 1.5 / 1.4 | 25 | 0.06 / 0.05 | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 1 | |
| F1FJ4315E0 | Zugang anfordern | F1F J4 3 15 E 0 | EPDM | -10°C +140°C | Flansch 25x25 mm | 1.5 / 1.4 | 25 | 0.06 / 0.05 | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 0 - 13.5 bar | 1 | |
| F1FJ4302N0 | Zugang anfordern | F1F J4 3 02 N 0 | NBR | -10°C +90°C | Flansch 25x25 mm | 2 / 1.4 | 25 | 0.09 / 0.05 | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 1 | |
| F1FJ4302V0 | Zugang anfordern | F1F J4 3 02 V 0 | FKM | -10°C +140°C | Flansch 25x25 mm | 2 / 1.4 | 25 | 0.09 / 0.05 | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 1 | |
| F1FJ4302E0 | Zugang anfordern | F1F J4 3 02 E 0 | EPDM | -10°C +140°C | Flansch 25x25 mm | 2 / 1.4 | 25 | 0.09 / 0.05 | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 0 - 8 bar | 1 | |
| F1FJ4325N0 | Zugang anfordern | F1F J4 3 25 N 0 | NBR | -10°C +90°C | Flansch 25x25 mm | 2.5 / 1.4 | 25 | 0.15 / 0.05 | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 1 | |
| F1FJ4325V0 | Zugang anfordern | F1F J4 3 25 V 0 | FKM | -10°C +140°C | Flansch 25x25 mm | 2.5 / 1.4 | 25 | 0.15 / 0.05 | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 1 | |
| F1FJ4325E0 | Zugang anfordern | F1F J4 3 25 E 0 | EPDM | -10°C +140°C | Flansch 25x25 mm | 2.5 / 1.4 | 25 | 0.15 / 0.05 | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 0 - 5 bar | 1 |
