Filter
| Code | 3D-Zeichnungen | Nummer | Dichtungswerkstoffe | Temperatur | Verbindungen | Ø Dn - IN/EXH (mm) | Viskosität (cSt) | Kv - IN/EXH (m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - DC (14 W) | OPD (ΔP) - DC (22 W) | OPD (ΔP) - AC (14 VA) | OPD (ΔP) - AC (21 VA) | OPD (ΔP) - AC (31 VA) | Verpackung | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02F03325V0 | Zugang anfordern | 02F 03 3 25 V 0 | FKM | -10°C +140°C | 1/4" | 2.5 / 1.9 | 37 | 0.15 / 0.10 | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 1 | |
| 02F03325N0 | Zugang anfordern | 02F 03 3 25 N 0 | NBR | -10°C +90°C | 1/4" | 2.5 / 1.9 | 37 | 0.15 / 0.10 | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 1 | |
| 02F03325E0 | Zugang anfordern | 02F 03 3 25 E 0 | EPDM | -10°C +140°C | 1/4" | 2.5 / 1.9 | 37 | 0.15 / 0.10 | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 1 | |
| 02F03325C0 | Zugang anfordern | 02F 03 3 25 C 0 | CR | -35°C +100°C | 1/4" | 2.5 / 1.9 | 37 | 0.15 / 0.10 | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 0 - 13 bar | 1 | |
| 02F03315V0 | Zugang anfordern | 02F 03 3 15 V 0 | FKM | -10°C +140°C | 1/4" | 1.5 / 1.9 | 25 | 0.06 / 0.10 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 | |
| 02F03315N0 | Zugang anfordern | 02F 03 3 15 N 0 | NBR | -10°C +90°C | 1/4" | 1.5 / 1.9 | 25 | 0.06 / 0.10 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 | |
| 02F03315E0 | Zugang anfordern | 02F 03 3 15 E 0 | EPDM | -10°C +140°C | 1/4" | 1.5 / 1.9 | 25 | 0.06 / 0.10 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 | |
| 02F03315C0 | Zugang anfordern | 02F 03 3 15 C 0 | CR | -35°C +100°C | 1/4" | 1.5 / 1.9 | 25 | 0.06 / 0.10 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 | |
| 02F03305V0 | Zugang anfordern | 02F 03 3 05 V 0 | FKM | -10°C +140°C | 1/4" | 5 / 1.9 | 37 | 0.51 / 0.10 | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 1 | |
| 02F03305N0 | Zugang anfordern | 02F 03 3 05 N 0 | NBR | -10°C +90°C | 1/4" | 5 / 1.9 | 37 | 0.51 / 0.10 | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 1 | |
| 02F03305E0 | Zugang anfordern | 02F 03 3 05 E 0 | EPDM | -10°C +140°C | 1/4" | 5 / 1.9 | 37 | 0.51 / 0.10 | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 1 | |
| 02F03305C0 | Zugang anfordern | 02F 03 3 05 C 0 | CR | -35°C +100°C | 1/4" | 5 / 1.9 | 37 | 0.51 / 0.10 | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 0 - 3 bar | 1 | |
| 02F03304V0 | Zugang anfordern | 02F 03 3 04 V 0 | FKM | -10°C +140°C | 1/4" | 4 / 1.9 | 37 | 0.35 / 0.10 | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 1 | |
| 02F03304N0 | Zugang anfordern | 02F 03 3 04 N 0 | NBR | -10°C +90°C | 1/4" | 4 / 1.9 | 37 | 0.35 / 0.10 | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 1 | |
| 02F03304E0 | Zugang anfordern | 02F 03 3 04 E 0 | EPDM | -10°C +140°C | 1/4" | 4 / 1.9 | 37 | 0.35 / 0.10 | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 1 | |
| 02F03304C0 | Zugang anfordern | 02F 03 3 04 C 0 | CR | -35°C +100°C | 1/4" | 4 / 1.9 | 37 | 0.35 / 0.10 | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 0 - 6 bar | 1 | |
| 02F03303V0 | Zugang anfordern | 02F 03 3 03 V 0 | FKM | -10°C +140°C | 1/4" | 3 / 1.9 | 37 | 0.21 / 0.10 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| 02F03303N0 | Zugang anfordern | 02F 03 3 03 N 0 | NBR | -10°C +90°C | 1/4" | 3 / 1.9 | 37 | 0.21 / 0.10 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| 02F03303E0 | Zugang anfordern | 02F 03 3 03 E 0 | EPDM | -10°C +140°C | 1/4" | 3 / 1.9 | 37 | 0.21 / 0.10 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| 02F03303C0 | Zugang anfordern | 02F 03 3 03 C 0 | CR | -35°C +100°C | 1/4" | 3 / 1.9 | 37 | 0.21 / 0.10 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| 02F03302V0 | Zugang anfordern | 02F 03 3 02 V 0 | FKM | -10°C +140°C | 1/4" | 2 / 1.9 | 37 | 0.10 / 0.10 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| 02F03302N0 | Zugang anfordern | 02F 03 3 02 N 0 | NBR | -10°C +90°C | 1/4" | 2 / 1.9 | 37 | 0.10 / 0.10 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| 02F03302E0 | Zugang anfordern | 02F 03 3 02 E 0 | EPDM | -10°C +140°C | 1/4" | 2 / 1.9 | 37 | 0.10 / 0.10 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| 02F03302C0 | Zugang anfordern | 02F 03 3 02 C 0 | CR | -35°C +100°C | 1/4" | 2 / 1.9 | 37 | 0.10 / 0.10 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 |
