Code | Dessins 3D | Matériau joint | Température | Connexions | Ø Passage (mm) | Viscosité (cSt) | Kv (m3/h) | OPD (ΔP) - DC (14 W) | OPD (ΔP) - AC (14 VA) | Conditionnement | |
---|---|---|---|---|---|---|---|---|---|---|---|
08F 02 2 19 N 0 | Demander l'accès | NBR | -10°C +90°C | 1/8" | 1.9 | 25 | 0.11 | 0 - 25 bar | 0 - 25 bar | 1 | |
08F 02 2 19 V 0 | Demander l'accès | FKM | -10°C +140°C | 1/8" | 1.9 | 25 | 0.11 | 0 - 25 bar | 0 - 25 bar | 1 | |
08F 02 2 19 E 0 | Demander l'accès | EPDM | -10°C +140°C | 1/8" | 1.9 | 25 | 0.11 | 0 - 25 bar | 0 - 25 bar | 1 | |
08F 02 2 23 N 0 | Demander l'accès | NBR | -10°C +90°C | 1/8" | 2.3 | 25 | 0.14 | 0 - 20 bar | 0 - 20 bar | 1 | |
08F 02 2 23 V 0 | Demander l'accès | FKM | -10°C +140°C | 1/8" | 2.3 | 25 | 0.14 | 0 - 20 bar | 0 - 20 bar | 1 | |
08F 02 2 23 E 0 | Demander l'accès | EPDM | -10°C +140°C | 1/8" | 2.3 | 25 | 0.14 | 0 - 20 bar | 0 - 20 bar | 1 |
