Serie X2F - 2/2 NO
ELECTROVÁLVULAS DE ACCIONAMIENTO DIRECTO
| Código | Dibujos 3D | Material juntas | Temperatura | Conexiones | Ø Orificio (mm) | Viscosidad (cSt) | Kv (m3/h) | OPD (ΔP) - DC (14 W) | OPD (ΔP) - DC (22 W) | OPD (ΔP) - AC (14 VA) | OPD (ΔP) - AC (21 VA) | OPD (ΔP) - AC (31 VA) | Embute | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| X2F 03 2 15 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 | |
| X2F 03 2 15 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 | |
| X2F 03 2 15 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 | |
| X2F 03 2 02 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 2 | 37 | 0.1 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X2F 03 2 02 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 2 | 37 | 0.1 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X2F 03 2 02 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 2 | 37 | 0.1 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X2F 03 2 25 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 1 | |
| X2F 03 2 25 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 1 | |
| X2F 03 2 25 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 1 | |
| X2F 03 2 03 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 3 | 53 | 0.21 | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 1 | |
| X2F 03 2 03 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 3 | 53 | 0.21 | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 1 | |
| X2F 03 2 03 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 3 | 53 | 0.21 | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 1 | |
| X2F 03 2 04 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 4 | 53 | 0.35 | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 1 | |
| X2F 03 2 04 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 4 | 53 | 0.35 | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 1 | |
| X2F 03 2 04 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 4 | 53 | 0.35 | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 1 | |
| X2F 03 2 05 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 5 | 53 | 0.51 | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 1 | |
| X2F 03 2 05 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 5 | 53 | 0.51 | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 1 | |
| X2F 03 2 05 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 5 | 53 | 0.51 | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 0 - 2.5 bar | 1 |
