| Código | Dibujos 3D | Material juntas | Temperatura | Conexiones | Ø Orificio (mm) | Viscosidad (cSt) | Kv (m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - AC (7.5 VA) | OPD (ΔP) - AC (11 VA) | OPD (ΔP) - AC (5.3 W) - Atex Ex m | Embute | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| X1F 02 2 15 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/8" | 1.5 | 25 | 0.06 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X1F 02 2 15 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/8" | 1.5 | 25 | 0.06 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X1F 02 2 15 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/8" | 1.5 | 25 | 0.06 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X1F 02 2 15 C 0 | Solicitar acceso | CR | -35°C +100°C | 1/8" | 1.5 | 25 | 0.06 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X1F 02 2 02 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/8" | 2 | 37 | 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| X1F 02 2 02 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/8" | 2 | 37 | 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| X1F 02 2 02 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/8" | 2 | 37 | 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| X1F 02 2 02 C 0 | Solicitar acceso | CR | -35°C +100°C | 1/8" | 2 | 37 | 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| X1F 02 2 25 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/8" | 2.5 | 53 | 0.15 | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 1 | |
| X1F 02 2 25 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/8" | 2.5 | 53 | 0.15 | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 1 | |
| X1F 02 2 25 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/8" | 2.5 | 53 | 0.15 | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 1 | |
| X1F 02 2 25 C 0 | Solicitar acceso | CR | -35°C +100°C | 1/8" | 2.5 | 53 | 0.15 | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 1 | |
| X1F 02 2 03 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/8" | 3 | 53 | 0.20 | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 1 | |
| X1F 02 2 03 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/8" | 3 | 53 | 0.20 | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 1 | |
| X1F 02 2 03 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/8" | 3 | 53 | 0.20 | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 1 | |
| X1F 02 2 03 C 0 | Solicitar acceso | CR | -35°C +100°C | 1/8" | 3 | 53 | 0.20 | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 1 | |
| X1F 03 2 15 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X1F 03 2 15 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X1F 03 2 15 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X1F 03 2 15 C 0 | Solicitar acceso | CR | -35°C +100°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 | |
| X1F 03 2 02 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 2 | 37 | 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| X1F 03 2 02 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 2 | 37 | 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| X1F 03 2 02 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 2 | 37 | 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| X1F 03 2 02 C 0 | Solicitar acceso | CR | -35°C +100°C | 1/4" | 2 | 37 | 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 | |
| X1F 03 2 25 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 1 | |
| X1F 03 2 25 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 1 | |
| X1F 03 2 25 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 1 | |
| X1F 03 2 25 C 0 | Solicitar acceso | CR | -35°C +100°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 0 - 6.5 bar | 1 | |
| X1F 03 2 03 N 0 | Solicitar acceso | NBR | -10°C +90°C | 1/4" | 3 | 53 | 0.20 | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 1 | |
| X1F 03 2 03 V 0 | Solicitar acceso | FKM | -10°C +140°C | 1/4" | 3 | 53 | 0.20 | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 1 | |
| X1F 03 2 03 E 0 | Solicitar acceso | EPDM | -10°C +140°C | 1/4" | 3 | 53 | 0.20 | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 1 | |
| X1F 03 2 03 C 0 | Solicitar acceso | CR | -35°C +100°C | 1/4" | 3 | 53 | 0.20 | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 0 - 4.2 bar | 1 |
