| Code | 3D Drawings | Ext. mm | Int. mm | Color | Bending Radius | Working Pressure (at 20 °C) | Burst Pressure (at 20 °C) | Temperature Range | Tolerance | Bag | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TS12 31 721 NE | Request access | 1/8 (3.17) | 2.18 | Black | 25 mm | 24 bar | 74 bar | From -40 °C to +100 °C | ± 0,07 mm | 1 | |
| TS12 63 543 NE | Request access | 1/4 (6.35) | 4.35 | Black | 40 mm | 24 bar | 74 bar | From -40 °C to +100 °C | ± 0,07 mm | 1 | |
| TS12 95 271 NE | Request access | 3/8 (9.52) | 7.14 | Black | 55 mm | 19 bar | 57 bar | From -40 °C to +100 °C | ± 0,07 mm | 1 | |
| TS12 12 795 NE | Request access | 1/2 (12.7) | 9.52 | Black | 65 mm | 19 bar | 57 bar | From -40 °C to +100 °C | ± 0,10 mm | 1 |
