| Code | 3D Drawings | Ext. mm | Int. mm | Color | Bending Radius | Working Pressure (at 20 °C) | Burst Pressure (at 20 °C) | Temperature Range | Tolerance | Bag | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TBFE 00 425 NT | Request access | 4 | 2,5 | Neutral | 21 mm | 22 bar | 110 bar | From -60 °C to +205 °C | ± 0,07 mm | 50 Mt | |
| TBFE 00 640 NT | Request access | 6 | 4 | Neutral | 36 mm | 19 bar | 96 bar | From -60 °C to +205 °C | ± 0,07 mm | 50 Mt | |
| TBFE 00 860 NT | Request access | 8 | 6 | Neutral | 64 mm | 14 bar | 70 bar | From -60 °C to +205 °C | ± 0,07 mm | 50 Mt | |
| TBFE 01 080 NT | Request access | 10 | 8 | Neutral | 100 mm | 11 bar | 55 bar | From -60 °C to +205 °C | ± 0,07 mm | 50 Mt | |
| TBFE 12 100 NT | Request access | 12 | 10 | Neutral | 144 mm | 9 bar | 45 bar | From -60 °C to +205 °C | ± 0,07 mm | 50 Mt | |
| TBFE 14 120 NT | Request access | 14 | 12 | Neutral | 196 mm | 8 bar | 25 bar | From -60 °C to +205 °C | ± 0,15 mm | 50 Mt | |
| TBFE 16 140 NT | Request access | 16 | 14 | Neutral | 256 mm | 6 bar | 20 bar | From -60 °C to +205 °C | ± 0,15 mm | 50 Mt |
