| Code | 3D Drawings | Ext. mm | Int. mm | Color | Bending Radius | Working Pressure (at 20 °C) | Burst Pressure (at 20 °C) | Temperature Range | Tolerance | Bag | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| TSFE 00 425 NT | Request access | 4 | 2,5 | Neutral | 21 mm | 22 bar | 110 bar | From -60 °C to +205 °C | ± 0,07 mm | 1 | |
| TSFE 00 640 NT | Request access | 6 | 4 | Neutral | 36 mm | 19 bar | 96 bar | From -60 °C to +205 °C | ± 0,07 mm | 1 | |
| TSFE 00 860 NT | Request access | 8 | 6 | Neutral | 64 mm | 14 bar | 70 bar | From -60 °C to +205 °C | ± 0,07 mm | 1 | |
| TSFE 01 080 NT | Request access | 10 | 8 | Neutral | 100 mm | 11 bar | 55 bar | From -60 °C to +205 °C | ± 0,07 mm | 1 | |
| TSFE 12 100 NT | Request access | 12 | 10 | Neutral | 144 mm | 9 bar | 46 bar | From -60 °C to +205 °C | ± 0,07 mm | 1 |
