Filter
T8400
TUBE IN PA12HR
| Code | 3D Drawings | Tube | Ext. mm | Int. mm | Bending Radius | Working Pressure (at 20 °C) | Temperature Range | Bag | |
|---|---|---|---|---|---|---|---|---|---|
| T8400 00 31 00 NE | Request access | 1/4 | 6,35 | 3,6 | 30 mm | 77 bar | From -40 °C to +80 °C | 100 Mt | |
| T8400 00 31 00 GR | Request access | 1/4 | 6,35 | 3,6 | 30 mm | 77 bar | From -40 °C to +80 °C | 100 Mt | |
| T8400 00 41 00 NE | Request access | 3/8 | 9,52 | 5 | 35 mm | 87 bar | From -40 °C to +80 °C | 100 Mt | |
| T8400 00 41 00 GR | Request access | 3/8 | 9,52 | 5 | 35 mm | 87 bar | From -40 °C to +80 °C | 100 Mt |
