DOUBLE ACTING MAGNETIC SLIDE - Bore from 6 to 25

Code	3D Drawings	Ø	Stroke
CG04 006 0010	Request access	6	10
CG04 006 0020	Request access	6	20
CG04 006 0030	Request access	6	30
CG04 006 0040	Request access	6	40
CG04 006 0050	Request access	6	50
CG04 008 0010	Request access	8	10
CG04 008 0020	Request access	8	20
CG04 008 0030	Request access	8	30
CG04 008 0040	Request access	8	40
CG04 008 0050	Request access	8	50
CG04 008 0075	Request access	8	75
CG04 012 0010	Request access	12	10
CG04 012 0020	Request access	12	20
CG04 012 0030	Request access	12	30
CG04 012 0040	Request access	12	40
CG04 012 0050	Request access	12	50
CG04 012 0075	Request access	12	75
CG04 012 0100	Request access	12	100
CG04 016 0010	Request access	16	10
CG04 016 0020	Request access	16	20
CG04 016 0030	Request access	16	30
CG04 016 0040	Request access	16	40
CG04 016 0050	Request access	16	50
CG04 016 0075	Request access	16	75
CG04 016 0100	Request access	16	100
CG04 016 0125	Request access	16	125
CG04 020 0010	Request access	20	10
CG04 020 0020	Request access	20	20
CG04 020 0030	Request access	20	30
CG04 020 0040	Request access	20	40
CG04 020 0050	Request access	20	50
CG04 020 0075	Request access	20	75
CG04 020 0100	Request access	20	100
CG04 020 0125	Request access	20	125
CG04 020 0150	Request access	20	150
CG04 025 0010	Request access	25	10
CG04 025 0020	Request access	25	20
CG04 025 0030	Request access	25	30
CG04 025 0040	Request access	25	40
CG04 025 0050	Request access	25	50
CG04 025 0075	Request access	25	75
CG04 025 0100	Request access	25	100
CG04 025 0125	Request access	25	125
CG04 025 0150	Request access	25	150
