Filter
| Code | 3D Drawings | Sealing material | Temperature | Port size | Ø Orifice (mm) | Viscosity (cSt) | Kv (m3/h) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - AC (12 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| X2A 03 1 15 C 0 | Request access | CR | -35°C +100°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 50 bar | 0 - 50 bar | 1 | |
| X2A 03 1 02 C 0 | Request access | CR | -35°C +100°C | 1/4" | 2 | 37 | 0.1 | 0 - 35 bar | 0 - 35 bar | 1 | |
| X2A 03 1 25 C 0 | Request access | CR | -35°C +100°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 21 bar | 0 - 21 bar | 1 | |
| X2A 03 1 03 C 0 | Request access | CR | -35°C +100°C | 1/4" | 3 | 53 | 0.21 | 0 - 10 bar | 0 - 10 bar | 1 | |
| X2A 03 1 04 C 0 | Request access | CR | -35°C +100°C | 1/4" | 4 | 53 | 0.35 | 0 - 3 bar | 0 - 3 bar | 1 | |
| X2A 03 1 05 C 0 | Request access | CR | -35°C +100°C | 1/4" | 5 | 53 | 0.51 | 0 - 1.4 bar | 0 - 1.4 bar | 1 | |
| X2A 03 1 15 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 50 bar | 0 - 50 bar | 1 | |
| X2A 03 1 15 F 0 | Request access | NBR | -40°C +90°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 50 bar | 0 - 50 bar | 1 | |
| X2A 03 1 15 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 50 bar | 0 - 50 bar | 1 | |
| X2A 03 1 15 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 50 bar | 0 - 50 bar | 1 | |
| X2A 03 1 15 P 0 | Request access | PTFE | -40°C +180°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 50 bar | 0 - 50 bar | 1 | |
| X2A 03 1 02 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 2 | 37 | 0.1 | 0 - 35 bar | 0 - 35 bar | 1 | |
| X2A 03 1 02 F 0 | Request access | NBR | -40°C +90°C | 1/4" | 2 | 37 | 0.1 | 0 - 35 bar | 0 - 35 bar | 1 | |
| X2A 03 1 02 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 2 | 37 | 0.1 | 0 - 35 bar | 0 - 35 bar | 1 | |
| X2A 03 1 02 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 2 | 37 | 0.1 | 0 - 35 bar | 0 - 35 bar | 1 | |
| X2A 03 1 02 P 0 | Request access | PTFE | -40°C +180°C | 1/4" | 2 | 37 | 0.1 | 0 - 35 bar | 0 - 35 bar | 1 | |
| X2A 03 1 25 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 21 bar | 0 - 21 bar | 1 | |
| X2A 03 1 25 F 0 | Request access | NBR | -40°C +90°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 21 bar | 0 - 21 bar | 1 | |
| X2A 03 1 25 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 21 bar | 0 - 21 bar | 1 | |
| X2A 03 1 25 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 21 bar | 0 - 21 bar | 1 | |
| X2A 03 1 25 P 0 | Request access | PTFE | -40°C +180°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 21 bar | 0 - 21 bar | 1 | |
| X2A 03 1 03 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 3 | 53 | 0.21 | 0 - 10 bar | 0 - 10 bar | 1 | |
| X2A 03 1 03 F 0 | Request access | NBR | -40°C +90°C | 1/4" | 3 | 53 | 0.21 | 0 - 10 bar | 0 - 10 bar | 1 | |
| X2A 03 1 03 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 3 | 53 | 0.21 | 0 - 10 bar | 0 - 10 bar | 1 | |
| X2A 03 1 03 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 3 | 53 | 0.21 | 0 - 10 bar | 0 - 10 bar | 1 | |
| X2A 03 1 03 P 0 | Request access | PTFE | -40°C +180°C | 1/4" | 3 | 53 | 0.21 | 0 - 10 bar | 0 - 10 bar | 1 | |
| X2A 03 1 04 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 4 | 53 | 0.35 | 0 - 3 bar | 0 - 3 bar | 1 | |
| X2A 03 1 04 F 0 | Request access | NBR | -40°C +90°C | 1/4" | 4 | 53 | 0.35 | 0 - 3 bar | 0 - 3 bar | 1 | |
| X2A 03 1 04 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 4 | 53 | 0.35 | 0 - 3 bar | 0 - 3 bar | 1 | |
| X2A 03 1 04 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 4 | 53 | 0.35 | 0 - 3 bar | 0 - 3 bar | 1 | |
| X2A 03 1 04 P 0 | Request access | PTFE | -40°C +180°C | 1/4" | 4 | 53 | 0.35 | 0 - 3 bar | 0 - 3 bar | 1 | |
| X2A 03 1 05 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 5 | 53 | 0.51 | 0 - 1.4 bar | 0 - 1.4 bar | 1 | |
| X2A 03 1 05 F 0 | Request access | NBR | -40°C +90°C | 1/4" | 5 | 53 | 0.51 | 0 - 1.4 bar | 0 - 1.4 bar | 1 | |
| X2A 03 1 05 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 5 | 53 | 0.51 | 0 - 1.4 bar | 0 - 1.4 bar | 1 | |
| X2A 03 1 05 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 5 | 53 | 0.51 | 0 - 1.4 bar | 0 - 1.4 bar | 1 | |
| X2A 03 1 05 P 0 | Request access | PTFE | -40°C +180°C | 1/4" | 5 | 53 | 0.51 | 0 - 1.4 bar | 0 - 1.4 bar | 1 |
