FORM A / EN 175301-803 (EX DIN 43650)
| Code | 3D Drawings | Reference | Ø Operator (mm) | Size (mm) | Voltage | Power | Bag | |
|---|---|---|---|---|---|---|---|---|
| SOL11 012 C 5 000 | Request access | BA | 10 | 30 | 12V DC | 8 W | 1 | |
| SOL11 024 C 5 000 | Request access | BB | 10 | 30 | 24V DC | 8 W | 1 | |
| SOL11 012 C L 000 | Request access | BH | 10 | 30 | 12V DC | 4 W | 1 | |
| SOL11 024 A 9 000 | Request access | B1 | 10 | 30 | 24V AC / 50-60 Hz | 11 VA | 1 | |
| SOL11 110 A 9 000 | Request access | B2 | 10 | 30 | 110V AC / 50-60 Hz | 11 VA | 1 | |
| SOL11 220 A 9 000 | Request access | B3 | 10 | 30 | 220V AC / 50-60 Hz | 11 VA | 1 |
