Filter
| Code | 3D Drawings | Sealing material | Temperature | Port size | Ø Orifice (mm) | Viscosity (cSt) | Kv (m3/h) | OPD (ΔP) - DC (2 W) | OPD (ΔP) - DC (3 W) | OPD (ΔP) - DC (4 W) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| X1F 03 B 25 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 2.5 bar | 0 - 5 bar | 0 - 10 bar | 1 | |
| X1F 03 B 25 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 2.5 bar | 0 - 5 bar | 0 - 10 bar | 1 | |
| X1F 03 B 25 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 2.5 bar | 0 - 5 bar | 0 - 10 bar | 1 | |
| X1F 03 B 25 C 0 | Request access | CR | -35°C +100°C | 1/4" | 2.5 | 53 | 0.15 | 0 - 2.5 bar | 0 - 5 bar | 0 - 10 bar | 1 | |
| X1F 03 B 15 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 20 bar | 0 - 35 bar | 1 | |
| X1F 03 B 15 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 20 bar | 0 - 35 bar | 1 | |
| X1F 03 B 15 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 20 bar | 0 - 35 bar | 1 | |
| X1F 03 B 15 C 0 | Request access | CR | -35°C +100°C | 1/4" | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 20 bar | 0 - 35 bar | 1 | |
| X1F 03 B 03 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 3 | 53 | 0.20 | - | 0 - 3 bar | 0 - 5.5 bar | 1 | |
| X1F 03 B 03 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 3 | 53 | 0.20 | - | 0 - 3 bar | 0 - 5.5 bar | 1 | |
| X1F 03 B 03 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 3 | 53 | 0.20 | - | 0 - 3 bar | 0 - 5.5 bar | 1 | |
| X1F 03 B 03 C 0 | Request access | CR | -35°C +100°C | 1/4" | 3 | 53 | 0.20 | - | 0 - 3 bar | 0 - 5.5 bar | 1 | |
| X1F 03 B 02 V 0 | Request access | FKM | -10°C +140°C | 1/4" | 2 | 37 | 0.09 | 0 - 6.5 bar | 0 - 13 bar | 0 - 23 bar | 1 | |
| X1F 03 B 02 N 0 | Request access | NBR | -10°C +90°C | 1/4" | 2 | 37 | 0.09 | 0 - 6.5 bar | 0 - 13 bar | 0 - 23 bar | 1 | |
| X1F 03 B 02 E 0 | Request access | EPDM | -10°C +140°C | 1/4" | 2 | 37 | 0.09 | 0 - 6.5 bar | 0 - 13 bar | 0 - 23 bar | 1 | |
| X1F 03 B 02 C 0 | Request access | CR | -35°C +100°C | 1/4" | 2 | 37 | 0.09 | 0 - 6.5 bar | 0 - 13 bar | 0 - 23 bar | 1 | |
| X1F 02 B 25 V 0 | Request access | FKM | -10°C +140°C | 1/8" | 2.5 | 53 | 0.15 | 0 - 2.5 bar | 0 - 5 bar | 0 - 10 bar | 1 | |
| X1F 02 B 25 N 0 | Request access | NBR | -10°C +90°C | 1/8" | 2.5 | 53 | 0.15 | 0 - 2.5 bar | 0 - 5 bar | 0 - 10 bar | 1 | |
| X1F 02 B 25 E 0 | Request access | EPDM | -10°C +140°C | 1/8" | 2.5 | 53 | 0.15 | 0 - 2.5 bar | 0 - 5 bar | 0 - 10 bar | 1 | |
| X1F 02 B 25 C 0 | Request access | CR | -35°C +100°C | 1/8" | 2.5 | 53 | 0.15 | 0 - 2.5 bar | 0 - 5 bar | 0 - 10 bar | 1 | |
| X1F 02 B 15 V 0 | Request access | FKM | -10°C +140°C | 1/8" | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 20 bar | 0 - 35 bar | 1 | |
| X1F 02 B 15 N 0 | Request access | NBR | -10°C +90°C | 1/8" | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 20 bar | 0 - 35 bar | 1 | |
| X1F 02 B 15 E 0 | Request access | EPDM | -10°C +140°C | 1/8" | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 20 bar | 0 - 35 bar | 1 | |
| X1F 02 B 15 C 0 | Request access | CR | -35°C +100°C | 1/8" | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 20 bar | 0 - 35 bar | 1 | |
| X1F 02 B 03 V 0 | Request access | FKM | -10°C +140°C | 1/8" | 3 | 53 | 0.20 | - | 0 - 3 bar | 0 - 5.5 bar | 1 | |
| X1F 02 B 03 N 0 | Request access | NBR | -10°C +90°C | 1/8" | 3 | 53 | 0.20 | - | 0 - 3 bar | 0 - 5.5 bar | 1 | |
| X1F 02 B 03 E 0 | Request access | EPDM | -10°C +140°C | 1/8" | 3 | 53 | 0.20 | - | 0 - 3 bar | 0 - 5.5 bar | 1 | |
| X1F 02 B 03 C 0 | Request access | CR | -35°C +100°C | 1/8" | 3 | 53 | 0.20 | - | 0 - 3 bar | 0 - 5.5 bar | 1 | |
| X1F 02 B 02 V 0 | Request access | FKM | -10°C +140°C | 1/8" | 2 | 37 | 0.09 | 0 - 6.5 bar | 0 - 13 bar | 0 - 23 bar | 1 | |
| X1F 02 B 02 N 0 | Request access | NBR | -10°C +90°C | 1/8" | 2 | 37 | 0.09 | 0 - 6.5 bar | 0 - 13 bar | 0 - 23 bar | 1 | |
| X1F 02 B 02 E 0 | Request access | EPDM | -10°C +140°C | 1/8" | 2 | 37 | 0.09 | 0 - 6.5 bar | 0 - 13 bar | 0 - 23 bar | 1 | |
| X1F 02 B 02 C 0 | Request access | CR | -35°C +100°C | 1/8" | 2 | 37 | 0.09 | 0 - 6.5 bar | 0 - 13 bar | 0 - 23 bar | 1 |
