Filter
| Code | 3D Drawings | Sealing material | Temperature | Port size | Ø Orifice (mm) | Viscosity (cSt) | Kv (m3/h) | OPD (ΔP) - DC (6.5 W) | OPD (ΔP) - AC (7.5 VA) | Package | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| T1F X1 3 15 N 0 | Request access | NBR | -10°C +90°C | Push-in Ø4 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X1 3 15 V 0 | Request access | FKM | -10°C +140°C | Push-in Ø4 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X1 3 15 E 0 | Request access | EPDM | -10°C +140°C | Push-in Ø4 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X1 3 15 C 0 | Request access | CR | -35°C +100°C | Push-in Ø4 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X1 3 02 N 0 | Request access | NBR | -10°C +90°C | Push-in Ø4 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X1 3 02 V 0 | Request access | FKM | -10°C +140°C | Push-in Ø4 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X1 3 02 E 0 | Request access | EPDM | -10°C +140°C | Push-in Ø4 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X1 3 02 C 0 | Request access | CR | -35°C +100°C | Push-in Ø4 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X1 3 25 N 0 | Request access | NBR | -10°C +90°C | Push-in Ø4 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X1 3 25 V 0 | Request access | FKM | -10°C +140°C | Push-in Ø4 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X1 3 25 E 0 | Request access | EPDM | -10°C +140°C | Push-in Ø4 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X1 3 25 C 0 | Request access | CR | -35°C +100°C | Push-in Ø4 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X4 3 15 N 0 | Request access | NBR | -10°C +90°C | Push-in Ø6 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X4 3 15 V 0 | Request access | FKM | -10°C +140°C | Push-in Ø6 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X4 3 15 E 0 | Request access | EPDM | -10°C +140°C | Push-in Ø6 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X4 3 15 C 0 | Request access | CR | -35°C +100°C | Push-in Ø6 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X4 3 02 N 0 | Request access | NBR | -10°C +90°C | Push-in Ø6 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X4 3 02 V 0 | Request access | FKM | -10°C +140°C | Push-in Ø6 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X4 3 02 E 0 | Request access | EPDM | -10°C +140°C | Push-in Ø6 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X4 3 02 C 0 | Request access | CR | -35°C +100°C | Push-in Ø6 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X4 3 25 N 0 | Request access | NBR | -10°C +90°C | Push-in Ø6 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X4 3 25 V 0 | Request access | FKM | -10°C +140°C | Push-in Ø6 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X4 3 25 E 0 | Request access | EPDM | -10°C +140°C | Push-in Ø6 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X4 3 25 C 0 | Request access | CR | -35°C +100°C | Push-in Ø6 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X4 3 03 N 0 | Request access | NBR | -10°C +90°C | Push-in Ø6 | 3 | 53 | 0.20 | - | - | 1 | |
| T1F X4 3 03 V 0 | Request access | FKM | -10°C +140°C | Push-in Ø6 | 3 | 53 | 0.20 | - | - | 1 | |
| T1F X4 3 03 E 0 | Request access | EPDM | -10°C +140°C | Push-in Ø6 | 3 | 53 | 0.20 | - | - | 1 | |
| T1F X4 3 03 C 0 | Request access | CR | -35°C +100°C | Push-in Ø6 | 3 | 53 | 0.20 | - | - | 1 | |
| T1F X4 3 15 N 1 | Request access | NBR | -10°C +90°C | Hose barb Ø6 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X4 3 15 V 1 | Request access | FKM | -10°C +140°C | Hose barb Ø6 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X4 3 15 E 1 | Request access | EPDM | -10°C +140°C | Hose barb Ø6 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X4 3 15 C 1 | Request access | CR | -35°C +100°C | Hose barb Ø6 | 1.5 | 25 | 0.06 | 0 - 10 bar | 0 - 10 bar | 1 | |
| T1F X4 3 02 N 1 | Request access | NBR | -10°C +90°C | Hose barb Ø6 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X4 3 02 V 1 | Request access | FKM | -10°C +140°C | Hose barb Ø6 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X4 3 02 E 1 | Request access | EPDM | -10°C +140°C | Hose barb Ø6 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X4 3 02 C 1 | Request access | CR | -35°C +100°C | Hose barb Ø6 | 2 | 37 | 0.09 | 0 - 6 bar | 0 - 6 bar | 1 | |
| T1F X4 3 25 N 1 | Request access | NBR | -10°C +90°C | Hose barb Ø6 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X4 3 25 V 1 | Request access | FKM | -10°C +140°C | Hose barb Ø6 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X4 3 25 E 1 | Request access | EPDM | -10°C +140°C | Hose barb Ø6 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 | |
| T1F X4 3 25 C 1 | Request access | CR | -35°C +100°C | Hose barb Ø6 | 2.5 | 53 | 0.15 | 0 - 4 bar | 0 - 4 bar | 1 |
