90826
BALANCER WITH COILED TUBING
Technical characteristics / catalogAignep Scan Labels Instructions Certifications
| Code | Capacity Kg | Stainless Steel Rope | Stroke Rope | Tube PA12 Int. | Tube PA12 Ext. | Max Press. | Temperature | Inlet - Outlet Fitting | Cut Down Size Tube | Air | Bag |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 90826 000 01 | 0,4÷1 | Ø 2mm | 1600mm | Ø 8mm (5/16") | Ø 10mm | 10bar (1Mpa) | -20/+80° | Push-in Fittings Ø 10 | 1 mt | YES | 1 |
| 90826 000 02 | 1÷2 | Ø 2mm | 1600mm | Ø 8mm (5/16") | Ø 10mm | 10bar (1Mpa) | -20/+80° | Push-in Fittings Ø 10 | 1 mt | YES | 1 |
| 90826 000 03 | 2÷3 | Ø 2mm | 1600mm | Ø 8mm (5/16") | Ø 10mm | 10bar (1Mpa) | -20/+80° | Push-in Fittings Ø 10 | 1 mt | YES | 1 |
