Serie F2F - 2/2 NO
DIRECT ACTING SOLENOID VALVES WITH FLANGE FIXING
Technical characteristics / catalogAignep Scan Labels Certifications
| Code | Draw | Sealing material | Temperature | Port size | Ø Orifice (mm) | Viscosity (cSt) | Kv (m3/h) | OPD (ΔP) - DC (14 W) | OPD (ΔP) - DC (22 W) | OPD (ΔP) - AC (14 VA) | OPD (ΔP) - AC (21 VA) | OPD (ΔP) - AC (31 VA) | Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| F2F J9 2 15 N 0 | Download | NBR | -10°C +90°C | Flange 32x32 mm | 1.5 | 25 | 0.06 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 |
| F2F J9 2 15 V 0 | Download | FKM | -10°C +140°C | Flange 32x32 mm | 1.5 | 25 | 0.06 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 |
| F2F J9 2 15 E 0 | Download | EPDM | -10°C +140°C | Flange 32x32 mm | 1.5 | 25 | 0.06 | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 0 - 25 bar | 1 |
| F2F J9 2 02 N 0 | Download | NBR | -10°C +90°C | Flange 32x32 mm | 2 | 37 | 0.1 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 |
| F2F J9 2 02 V 0 | Download | FKM | -10°C +140°C | Flange 32x32 mm | 2 | 37 | 0.1 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 |
| F2F J9 2 02 E 0 | Download | EPDM | -10°C +140°C | Flange 32x32 mm | 2 | 37 | 0.1 | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 0 - 18 bar | 1 |
| F2F J9 2 25 N 0 | Download | NBR | -10°C +90°C | Flange 32x32 mm | 2.5 | 53 | 0.15 | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 1 |
| F2F J9 2 25 V 0 | Download | FKM | -10°C +140°C | Flange 32x32 mm | 2.5 | 53 | 0.15 | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 1 |
| F2F J9 2 25 E 0 | Download | EPDM | -10°C +140°C | Flange 32x32 mm | 2.5 | 53 | 0.15 | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 0 - 12 bar | 1 |
| F2F J9 2 03 N 0 | Download | NBR | -10°C +90°C | Flange 32x32 mm | 3 | 53 | 0.21 | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 1 |
| F2F J9 2 03 V 0 | Download | FKM | -10°C +140°C | Flange 32x32 mm | 3 | 53 | 0.21 | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 1 |
| F2F J9 2 03 E 0 | Download | EPDM | -10°C +140°C | Flange 32x32 mm | 3 | 53 | 0.21 | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 0 - 7.5 bar | 1 |
| F2F J9 2 04 N 0 | Download | NBR | -10°C +90°C | Flange 32x32 mm | 4 | 53 | 0.35 | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 1 |
| F2F J9 2 04 V 0 | Download | FKM | -10°C +140°C | Flange 32x32 mm | 4 | 53 | 0.35 | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 1 |
| F2F J9 2 04 E 0 | Download | EPDM | -10°C +140°C | Flange 32x32 mm | 4 | 53 | 0.35 | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 0 - 4.5 bar | 1 |
