Codice  Disegno 3D Materiale tenuta Temperatura Connessioni Ø Orifizio (mm) Viscosità (cSt) Kv (m3/h) OPD (ΔP) - DC (8 W) OPD (ΔP) - DC (14 W) OPD (ΔP) - DC (22 W) OPD (ΔP) - AC (14 VA) OPD (ΔP) - AC (21 VA) OPD (ΔP) - AC (31 VA) Confezione
90975 00 004     Download NBR -10°C +90°C 3/8" - 1/2" GAS 3 53 0.21 0 - 10 bar 0 - 16 bar 0 - 40 bar 0 - 21 bar 0 - 30 bar 0 - 40 bar 1
90976 00 004     Download NBR -10°C +90°C 3/8" - 1/2" NPTF 3 53 0.21 0 - 10 bar 0 - 16 bar 0 - 40 bar 0 - 21 bar 0 - 30 bar 0 - 40 bar 1
90975 00 005     Download NBR -10°C +90°C 1/2" - 1/2" GAS 3 53 0.21 0 - 10 bar 0 - 16 bar 0 - 40 bar 0 - 21 bar 0 - 30 bar 0 - 40 bar 1
90976 00 005     Download NBR -10°C +90°C 1/2" - 1/2" NPTF 3 53 0.21 0 - 10 bar 0 - 16 bar 0 - 40 bar 0 - 21 bar 0 - 30 bar 0 - 40 bar 1
Codice Disegno 3D Materiale tenuta Temperatura Connessioni Ø Orifizio (mm) Viscosità (cSt) Kv (m3/h) OPD (ΔP) - DC (8 W) OPD (ΔP) - DC (14 W) OPD (ΔP) - DC (22 W) OPD (ΔP) - AC (14 VA) OPD (ΔP) - AC (21 VA) OPD (ΔP) - AC (31 VA) Confezione
90975 00 004 Download NBR -10°C +90°C 3/8" - 1/2" GAS 3 53 0.21 0 - 10 bar 0 - 16 bar 0 - 40 bar 0 - 21 bar 0 - 30 bar 0 - 40 bar 1
90976 00 004 Download NBR -10°C +90°C 3/8" - 1/2" NPTF 3 53 0.21 0 - 10 bar 0 - 16 bar 0 - 40 bar 0 - 21 bar 0 - 30 bar 0 - 40 bar 1
90975 00 005 Download NBR -10°C +90°C 1/2" - 1/2" GAS 3 53 0.21 0 - 10 bar 0 - 16 bar 0 - 40 bar 0 - 21 bar 0 - 30 bar 0 - 40 bar 1
90976 00 005 Download NBR -10°C +90°C 1/2" - 1/2" NPTF 3 53 0.21 0 - 10 bar 0 - 16 bar 0 - 40 bar 0 - 21 bar 0 - 30 bar 0 - 40 bar 1

* Temporizzatore non incluso (Cod. 90985) - Bobina non inclusa
