| Code | USA Ref | 3D Drawings | Drawing | Ways | Reactuation | Function | Size | Pack. | |
|---|---|---|---|---|---|---|---|---|---|
| 01V L0 3 NC 02 | 01VL03NC02 | Request access | 3/2 | LEVER OPERATED - SPRING RETURN | NC | G 1/8 | 1 | ||
| 01V L0 3 NC 03 | 01VL03NC03 | Request access | 3/2 | LEVER OPERATED - SPRING RETURN | NC | G 1/4 | 1 | ||
| 01V L1 3 00 02 | 01VL130002 | Request access | 3/2 | LEVER OPERATED - PUSH/PULL | G 1/8 | 1 | |||
| 01V L1 3 00 03 | 01VL130003 | Request access | 3/2 | LEVER OPERATED - PUSH/PULL | G 1/4 | 1 | |||
| 01V L0 5 00 02 | 01VL050002 | Request access | 5/2 | LEVER OPERATED - SPRING RETURN | G 1/8 | 1 | |||
| 01V L0 5 00 03 | 01VL050003 | Request access | 5/2 | LEVER OPERATED - SPRING RETURN | G 1/4 | 1 | |||
| 01V L1 5 00 02 | 01VL150002 | Request access | 5/2 | LEVER OPERATED - PUSH/PULL | G 1/8 | 1 | |||
| 01V L1 5 00 03 | 01VL150003 | Request access | 5/2 | LEVER OPERATED - PUSH/PULL | G 1/4 | 1 | |||
| 01V L0 7 CC 02 | 01VL07CC02 | Request access | 5/3 | LEVER OPERATED - SPRING CENTERED | CC | G 1/8 | 1 | ||
| 01V L0 7 CC 03 | 01VL07CC03 | Request access | 5/3 | LEVER OPERATED - SPRING CENTERED | CC | G 1/4 | 1 | ||
| 01V L0 7 OC 02 | 01VL07OC02 | Request access | 5/3 | LEVER OPERATED - SPRING CENTERED | OC | G 1/8 | 1 | ||
| 01V L0 7 OC 03 | 01VL07OC03 | Request access | 5/3 | LEVER OPERATED - SPRING CENTERED | OC | G 1/4 | 1 | ||
| 01V L0 7 PC 02 | 01VL07PC02 | Request access | 5/3 | LEVER OPERATED - SPRING CENTERED | PC | G 1/8 | 1 | ||
| 01V L0 7 PC 03 | 01VL07PC03 | Request access | 5/3 | LEVER OPERATED - SPRING CENTERED | PC | G 1/4 | 1 | ||
| 01V L2 7 CC 02 | 01VL27CC02 | Request access | 5/3 | LEVER OPERATED - PUSH/PULL | CC | G 1/8 | 1 | ||
| 01V L2 7 CC 03 | 01VL27CC03 | Request access | 5/3 | LEVER OPERATED - PUSH/PULL | CC | G 1/4 | 1 | ||
| 01V L2 7 OC 02 | 01VL27OC02 | Request access | 5/3 | LEVER OPERATED - PUSH/PULL | OC | G 1/8 | 1 | ||
| 01V L2 7 OC 03 | 01VL27OC03 | Request access | 5/3 | LEVER OPERATED - PUSH/PULL | OC | G 1/4 | 1 | ||
| 01V L2 7 PC 02 | 01VL27PC02 | Request access | 5/3 | LEVER OPERATED - PUSH/PULL | PC | G 1/8 | 1 | ||
| 01V L2 7 PC 03 | 01VL27PC03 | Request access | 5/3 | LEVER OPERATED - PUSH/PULL | PC | G 1/4 | 1 |
