Serie 01F - 3/2 NO
ELECTROVÁLVULAS DE ACCIONAMIENTO DIRECTO
Características técnicas / catálogoEtiquetas aignep scan Certificaciones
| Código | Diseño 3D | Material juntas | Temperatura | Conexiones | Ø Orificio - IN/EXH (mm) | Viscosidad (cSt) | Kv - IN/EXH (m3/h) | OPD (ΔP) - DC (6.5 W) | OPD (ΔP) - DC (8 W) | OPD (ΔP) - AC (7.5 VA) | OPD (ΔP) - AC (11 VA) | OPD (ΔP) - DC (5.3 W) - Atex Ex m | OPD (ΔP) - AC (5.3 W) - Atex Ex m | Embute |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 01F 02 4 15 N 0 | Download | NBR | -10°C +90°C | 1/8" | 1.4 / 1.5 | 25 | 0.05 / 0.06 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 02 4 15 V 0 | Download | FKM | -10°C +140°C | 1/8" | 1.4 / 1.5 | 25 | 0.05 / 0.06 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 02 4 15 E 0 | Download | EPDM | -10°C +140°C | 1/8" | 1.4 / 1.5 | 25 | 0.05 / 0.06 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 02 4 02 N 0 | Download | NBR | -10°C +90°C | 1/8" | 1.4 / 2 | 25 | 0.05 / 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 02 4 02 V 0 | Download | FKM | -10°C +140°C | 1/8" | 1.4 / 2 | 25 | 0.05 / 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 02 4 02 E 0 | Download | EPDM | -10°C +140°C | 1/8" | 1.4 / 2 | 25 | 0.05 / 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 02 4 25 N 0 | Download | NBR | -10°C +90°C | 1/8" | 1.4 / 2.5 | 25 | 0.05 / 0.15 | 0 - 4 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 4 bar | 0 - 10 bar | 1 |
| 01F 02 4 25 V 0 | Download | FKM | -10°C +140°C | 1/8" | 1.4 / 2.5 | 25 | 0.05 / 0.15 | 0 - 4 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 4 bar | 0 - 10 bar | 1 |
| 01F 02 4 25 E 0 | Download | EPDM | -10°C +140°C | 1/8" | 1.4 / 2.5 | 25 | 0.05 / 0.15 | 0 - 4 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 4 bar | 0 - 10 bar | 1 |
| 01F 03 4 15 N 0 | Download | NBR | -10°C +90°C | 1/4" | 1.4 / 1.5 | 25 | 0.05 / 0.06 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 03 4 15 V 0 | Download | FKM | -10°C +140°C | 1/4" | 1.4 / 1.5 | 25 | 0.05 / 0.06 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 03 4 15 E 0 | Download | EPDM | -10°C +140°C | 1/4" | 1.4 / 1.5 | 25 | 0.05 / 0.06 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 03 4 02 N 0 | Download | NBR | -10°C +90°C | 1/4" | 1.4 / 2 | 25 | 0.05 / 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 03 4 02 V 0 | Download | FKM | -10°C +140°C | 1/4" | 1.4 / 2 | 25 | 0.05 / 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 03 4 02 E 0 | Download | EPDM | -10°C +140°C | 1/4" | 1.4 / 2 | 25 | 0.05 / 0.09 | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 1 |
| 01F 03 4 25 N 0 | Download | NBR | -10°C +90°C | 1/4" | 1.4 / 2.5 | 25 | 0.05 / 0.15 | 0 - 4 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 4 bar | 0 - 10 bar | 1 |
| 01F 03 4 25 V 0 | Download | FKM | -10°C +140°C | 1/4" | 1.4 / 2.5 | 25 | 0.05 / 0.15 | 0 - 4 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 4 bar | 0 - 10 bar | 1 |
| 01F 03 4 25 E 0 | Download | EPDM | -10°C +140°C | 1/4" | 1.4 / 2.5 | 25 | 0.05 / 0.15 | 0 - 4 bar | 0 - 10 bar | 0 - 10 bar | 0 - 10 bar | 0 - 4 bar | 0 - 10 bar | 1 |
